    15.6-Inch Windows Touch Embedded Screen for Smart City Displays, Stadium Interfaces, Immersive Retail Solutions, and Gaming Systems

    Ask Lasest Price
    Brand Name : ZXTLCD
    Model Number : ZXTLCD-RM156SWT
    Certification : CE/Rohs/FCC
    Price : negotiable
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 2000 pcs per month
    Delivery Time : 3-5 working days
    • Product Details
    • Company Profile

    15.6-Inch Windows Touch Embedded Screen for Smart City Displays, Stadium Interfaces, Immersive Retail Solutions, and Gaming Systems

    15.6-Inch Windows Touch Embedded Screen for Smart City Displays, Stadium Interfaces, Immersive Retail Solutions, and Gaming Systems

    15.6-inch embedded fully enclosed industrial control display: A reliable window for intelligent environmental monitoring instruments


    As people's awareness of environmental protection increases, intelligent environmental monitoring systems are gradually coming into the public eye. These systems can not only monitor environmental parameters such as air quality and water pollution in real-time but also upload data to the cloud for analysis. Among these systems, the 15.6-inch embedded fully enclosed industrial control display, with its outstanding performance and protective capabilities, has become a key display and operation unit.

    15.6-inch embedded fully enclosed industrial control display - The Visual Hub in Environmental Monitoring

    In the process of environmental monitoring, the visualization of data is very important. The 15.6-inch embedded fully enclosed industrial control display ensures clear presentation of monitoring data with its high definition and wide viewing angle features. Additionally, this display adopts a fully enclosed design, effectively preventing dust and moisture intrusion, allowing it to work stably for a long time even in outdoor or industrial environments. Whether it is temperature changes or direct sunlight, its display effect will not be affected, providing users with a clear and reliable observation window.

    Convenient Operation and Powerful Functions — 15.6-inch Android Touch Industrial Control Display

    As part of the intelligent environmental monitoring system, the 15.6-inch Android touch industrial control display not only provides excellent display effects but also supports multi-touch operation, making data queries and device settings simpler and more intuitive. Based on the openness of the Android system, users can install various applications according to their actual needs, expanding the functionality of the display. Whether it's real-time data display, historical record queries, or alarm notifications, this display can easily handle it, providing strong support for environmental monitoring.

    LCD Panel ParametersScreen Size15.6 Inch
    Display Area344.2 mm.(Height) X 193.5(Width)mm.
    Aspect Ratio16 : 9
    LCD Typea-Si TFT-LCD Monitor
    Maximum Resolution1920 X 1080
    Display Color16.7M , 72% NTSC
    Brightness250cd/
    Contrast Ratio700 : 1
    Viewing Angle (Up/Down/Left/Right)89°/89°/89°/89° (Type)(CR≥10)
    Response Time30ms
    LCD Panel Lifespan (Hours)60,000(Hour.)
    Field Frequency60Hertz
    PCAP Touchscreen Panel ParametersTouch PatternProjected Capacitive Touchscreen Monitor
    Touch Points10 Points
    Cover GlassPhysical toughened Morse magnitude 7 explosion-proof
    Glass 3 mm. Optical mount to reduce parallax
    Glass Transmission>85% (Higher light transmission depends on glass coating technology For example AR/AG) >85%
    Response Speed< 6ms
    Touch AccuracyMore than 90% of the touch area ±2 mm
    Touch MethodInch Stylus
    Output FormatCoordinate Output
    Click TimeUnlimited
    Smallest Touch Size5 mm
    Long-lasting DurabilityYes, Available
    Touch InterfaceUSB
    Operating Temperature and HumidityBelow 10 ~ +50, ≤ 85%RH
    Storage Temperature and HumidityLess than 20 ~ +60, ≤ 90%RH
    Internal computer configuration
    (Choose one of two)
    CPUIntel i5-4310M Generation 4, Dual-Core Four Threads, Main frequency can reach up to 2.7GHzIntel I5-6100T Generation 6, Dual-Core Four Threads, Main frequency can reach up to 3.2GHz
    Graphics CardIntegrated Graphics Card Intel® HD 4600Integrated Graphics Card Intel® HD 530
    RAM4GB8GB
    Storage Memory Capacity128GB256GB
    OSWin10 or win11 OptionalWin10 or win11 Optional
    Wi-Fi Built-inSpeed 150Mbps 802.11n wifi IntegratedSpeed 150Mbps 802.11n wifi Integrated
    Media FormatVideo Formatwmv, avi, flv, rm, rmvb, mpeg, ts, mp4 etc.
    Audio FormatMP3, WMA
    Photo FormatBMP, JPEG, PNG, GIF etc.
    Onboard InterfaceNetwork portRJ45 X 1, 10M/100M Adjustable Ethernet
    HDMI1
    USB4
    PowerPower SupplyAlternating Current 100V~240V, 50/60Hz
    Maximum Power Loss≤ 30 Watt
    Standby Mode Power Loss< 1 Watt
    FeaturesOperating Temperature0 ~ 50
    Storage TemperatureBelow 10 ~ +60
    Package SizeDevice Dimensions389 X 249X 51.7mm.
    Net Weight5 Kilogram
    Package Size44.2 X 30 X 10.5Centimeter
    Gross Package Weight per Unit5.5 Kilogram

    The 15.6-inch embedded fully enclosed industrial control display, with its excellent protective performance and user-friendly interaction design, has become an indispensable component of the intelligent environmental monitoring system, contributing to environmental management and protection.
