    SMTCL Large Lathe Machine CW6180B Manual Lathe 6000mm Heavy Duty Engine Lathe Turning Machine

    Ask Lasest Price
    Brand Name : SMTCL
    Model Number : CW6180B
    Certification : CE ISO certification
    Payment Terms : T/T, L/C,, Western Union
    Supply Ability : 50 sets per month
    Delivery Time : 45-60 days
    • Product Details
    • Company Profile

    SMTCL Large Lathe Machine CW6180B Manual Lathe 6000mm Heavy Duty Engine Lathe Turning Machine

    Product Description:

    SMTCL CW6180B Series Heavy Duty Manual Lathe
    CW6180B series Heavy-duty hand lathes are hand lathes specially designed for processing large, heavy-duty workpieces. It is larger in size and weight, has a stronger power output and a more stable structure. Spindle aperture, bed length and other dimensions are enlarged to meet the needs of large workpieces. The operation needs to cooperate with the lifting device, which requires higher skills and physical strength. This kind of lathe is usually used for large parts processing in the Marine, automotive, aerospace and other industries, and can meet the requirements of precision and dimensional accuracy, but the production efficiency is relatively low.

    Product Features:

    New Appearance

    The upgraded version of the appearance is a perfect hybrid of ergonomic design and sophisticated configuration of machine.
    The product quality has been enhanced by adoption of new materials.

    Easy Operation

    The handles and hand wheels are designed intuitively so that the machine is easy to operate, good for hand feeling and user-friendly. Fault operations for machine could be reduced
    effectively by the highlighted color and reasonable machine layout.

    Powerful Cutting

    CW6180B is a base-model machine product with a bed width of 550mm. The integral floor-type bed combined with stable diagonal bar construction is adopted to the high structural rigidity in its class. Large torque cutting can be realized by a large torque motor (11kW) combined with an optimized reduction speed headstock.

    Reliable Performance

    The machine is made with advanced manufacturing equipment.
    The production process strictly follows SOP and is under strict control of IS09000 QC system so as to ensure its reliab machining performance.
    Product Details:
    Product Paramenters:
    Item
    Unit
    CW6180B
    Max. Swing diameter over bed
    mm
    Φ800
    Max. Swing diameter over turret
    mm
    Φ480
    Max.Length of workpiece
    mm
    1000,,3000,4000,5000.6000,8000
    Max swing diameter and effective width in gap
    mm
    Φ1000/310
    Spindle bore diameter and type of spindle head
    Φ104/D11
    Taper of spindle nose and center
    120, 1:20. Morse 5#
    Steps and range of spindle speeds
    r/min
    18 speeds 5.4-720
    Steps and range of longitudinal feeds
    mm/r
    64 feeds 0.06-24.3
    Range 1:1
    mm/r
    0.1-1.52
    Range 16:1
    mm/r
    1.6-24.3
    Range of fine feed with change gears
    mm/r
    0.05-0.912
    Ration of cross feed to longitudinal feed
    1/2
    Rapid traverse of saddle
    mm/min
    4000
    Pitch of lead screw
    12 (Metric):1/2'' (Inch system)
    Number,range of Metric
    mm
    50 kinds 1-240
    Thread Number, range of Whitworth thread
    t.p.i
    26 kinds 14-1
    Number,range of module
    mm
    53 kinds 0.5-120
    ThreadNumber, range of diametral pitch thread
    DP
    24 kinds 28-1
    Max. Transverse travel of lower slide
    mm
    500
    Max.Travel of top slide
    mm
    200
    Travel of tailstock quill
    mm
    250
    Taper of tailstock quill
    Morse 5#
    Bed guideway width and hardness of quenching
    mm
    550 RC52
    Main motor power
    KW
    11/15
    Rapid motor power
    KW
    1.1
    Power of coolant pump motor
    W
    180
    Net weight
    kg
    4900
    Overall dimension
    mm
    3660x 1450x 1630
    Max. Load of workpiece
    T
    2.5(standard configuration)

    Standard configuration:

    1.Main motor: YE3-160M-4 11kW
    2.Fast motor: NJ12-4
    3.Cooling pump: YSB2-50
    4.Chuck: K11 315C/ A211

    5.Main shaft bearing:
    (1)NN3032K/P5 160X240X60
    (2)NN3026K/P5 130X200X52
    (3)6028 140X210X33
    Selective configuration:
    1.Steady rest Φ40-Φ350
    2.Follow rest Φ50-Φ220
    3.Φ400mm 3-jaw chuck
    4.Φ500mm 3-jaw chuck
    5.Φ400mm 4-jaw chuck
    6.Φ500mm 4-jaw chuck
    7.Φ630mm 4-jaw chuck
    8.Live centers Morse NO.5
    9.Φ650mm face plate

    OUR Service:

    Ensure you receive a high quality machine
    1. Every parts need be inspected

    2. Over 100 production process control
    3. Over 200 inspection items
    4. Sample processing of each machine
    5. 72 hours trial run before delivery
    Why Choose Us:
    ◆ Top quality sense, customers' requests come first
    ◆ 30 years + R & D history, the company was founded in 1993
    ◆ High-tech manufacturer with research anddesign capacity
    ◆ Stable and mature supplying system
    ◆ Young active sales and engineers for instant services(24 hours online)
    ◆ Upgrading on mechanism according to ergonomics and easy maintenance
    ◆ Our structure design principle: easy maintenance & installation, low cost maintenance, not affect production
    About Us:
    Welcome to visit us!
    Shanghai HD M&E Tech Co., Ltd is located in Shanghai, China. We specialize in CNC lathe, vertical machining center, horizontal machining center, gantry machining center, five-axis machining center, turn-milling center and various other CNC equipment. We have more than 200 kinds of machine tools. The quality and technology of products have reached the international advanced level.
    SMTCL and SYMG group is our cooperating factory. It has over 80 years’ history of manufacturing machine tools. The first lathe, drilling machine and boring machine were all born here. They have been one of the leader of China's Machine Tool industry and the largest machine tool manufacture in China. Machine tool products cover automobiles, aviation, new energy, construction machinery, ships, pump valves, bearings, 3C electronics, molds and other industries. We take the mission of providing the machine tools with leading technology, high quality and good service to our customers all over the world!
    Our Factory:

    FAQ:

    Q1. Are you a trade company or manufacturing company?

    We are a manufacturing company.
    Q2. What's your main products of your company?
    We specialized in all kinds of machines, such as CNC Lathe, CNC Milling Machine, Vertical Machining Center,Conventional Lathe, Drilling Machine, Radial Drilling Machine, and so on.
    Q3. Can you provide customized machine or SPM (Special purpose machine)?
    Yes, we provide Smart CNC solutions for our customer in order to increase efficiency.
    Q4: What's your warranty terms?
    We will supply a replacement for parts that prove to be defective for a period of 12 months,
    starting on the machine's bill of lading date.
    Q5. What is the services?
    Pr-sales:Customized solutions, planning and design;One-to-one service
    After sales:7 days 24 hours on line service, Remote guidance of installation, docking with customer software system
    Q6: Why choose your company?
    Products from the development, design, manufacture, assembly of the entire production process are
    carried out between plants with a complete production chain which is your most reliable guarantee.
    Q7: Can your company send the technical personnel to our company and direct our workers overseas?
    We can supply this kind of service. When the machines arrive the buyer's installation site, we can timely send mechanical and electrical engineers to install according to the buyer's schedule. All these can be quoted and list in the contract. The seller will cooperate with the buyer to deal with visa and installation preparation before going abroad.
    Q8: What's the Payment Terms?
    T/T 30% initial payment when order, 70% balance payment before shipment. irrevocable letter ofcredit at sight
