    Curved Rails 500T Load 20m/Min Motorized Transfer Trolley

    Ask Lasest Price
    Brand Name : BEFANBY
    Model Number : KPX - 1 - 500 ton
    Certification : CE,SGS,ISO9001
    Price : Negotiation
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 800 set/sets, per year
    Delivery Time : 40-50 days as usual delivery,30-40days for urgent delivery
    • Product Details
    • Company Profile

    Curved Rails 500T Load 20m/Min Motorized Transfer Trolley

    Top Leader KPX Series Motorized Transfer Platform Truck on Curved Rails
    1. The Brief Description of Top Leader KPX Series Motorized Transfer Platform Truck on Curved Rails

    The Top Leader KPX Series Motorized Transfer Platform Truck on Curved Rails are manufactured in capacities from 1 t up to 1,000 t. Its power supply is produced by the battery and movement is made by rail.(straight line travel or curved rails, all can be realized), which is popular material handling solution by battery operated

    The main character of the battery operated transfer truck


    1) The transfer truck can run on straight rail,“l”rail,“s”rail,arc-shaped rail,curved rails, etc.

    2)The transfer truck can be applied in many different severe environment,such as explosive environment,high temperature environment,ferry , anti-water, anti-dust occassions,etc.

    3) The transfer truck is driven by DC motor, the following advantages:stable start, starting torque, small impact to gear reducer, low voltage, long lifetime, etc.

    4) The transfer truck is maintenance free battery operated,so only charged fully,it can run freely without limited distance.
    5) The transfer truck can constantly run 4 hours for full load, and can work 8 hours if run for full load and return for empty.
    6) The charging time of the maintenance free battery is 8 hours.
    7)4/6/8 wheels run on the rails to realize turning





    The Application of the transfer truck manufactured by BEFANBY

    1. Open die in foundry plant
    2. Mold transfer in different area
    3. Die storage and transportation
    4. Raw material handling
    5. Coil transportation
    6. Military enterprise
    7. Ladle transfer
    8. Heavy machinery transfer
    9. Port handling





    2. Successful Solution About the Transfer PlatformTruck

    12 Sets KPX Series Motorized Transfer Platform Truck on Curved Rails had been delievered to our client from Guangdong. as per our client requirement, the transfer truck need to realize turning on curved rails when moving on the workshop . so BEFANBY engineer designed it to solve the workshop transport problem.

    If you'd like to see the video, please contact us, we will send to you

    Capacity16t (customized from 1-1,000t)
    Table Size3500*2000*700mm
    Rail Gauge1435mm
    Wheels No.12*350mm
    Running Speed0-20m/min, speed is adjusted
    ApplicationMarable slab transfer
    Special functionTurning, Customized platform







    3. BEFANBY Company



    Xinxiang Hundred Percent Electrical And Mechanical Co., Ltd is a professional manufacturer and exporter of material handling equipment since 2003. we can supply different powered transfer cart, such an battery powered, conductor rail powered, cable drum powered, dragged cable powered, busbar powered, no powered and so on. the transfer cart can run on rails or common cement floor.
