Brand Name : | BEFANBY |
Model Number : | KPX |
Certification : | CE,SGS,ISO9001 |
Price : | Negotiation |
Payment Terms : | L/C, T/T, Western Union |
Supply Ability : | 800 set/sets, per year |
Delivery Time : | 40-50 days as usual delivery,30-40days for urgent delivery |
roll plant electrical control system handle box sand blasting room transfer materials
roll plant electrical control system handle box sand blasting room transfer materials
roll plant electrical control system handle box sand blasting room transfer materials
roll plant electrical control system handle box sand blasting room transfer materials
roll plant electrical control system handle box sand blasting room transfer materials
roll plant electrical control system handle box sand blasting room transfer materials
Model | KPX-2t | KPX-5t | KPX-10t | KPX-16t | KPX-20t | KPX-25t | KPX-30t | KPX-40t | KPX-50t | KPX-63t | KPX-80t | KPX-100t | KPX-150t | |
Rated Load | 2 | 5 | 10 | 16 | 20 | 25 | 30 | 40 | 50 | 63 | 80 | 100 | 150 | |
Table size | Length(L) | 2000 | 3500 | 3600 | 4000 | 4000 | 4500 | 4500 | 5000 | 5500 | 5600 | 6000 | 6500 | 10000 |
Width(W) | 1500 | 2000 | 2000 | 2000 | 2200 | 2200 | 2200 | 2500 | 2500 | 2500 | 2600 | 2800 | 3000 | |
Height(H) | 450 | 500 | 500 | 550 | 550 | 600 | 600 | 650 | 650 | 700 | 800 | 900 | 1200 | |
Wheel Base | 1200 | 2500 | 2600 | 2800 | 2800 | 3200 | 3200 | 3800 | 4200 | 4300 | 4700 | 4900 | 7000 | |
Rail Inner Gauage | 1200 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1800 | 2000 | 2000 | |
Wheel Diameter | 270 | 300 | 300 | 350 | 350 | 400 | 400 | 500 | 500 | 600 | 600 | 600 | 600 | |
Wheel Quantity | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 8 | |
Ground Clearance | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 75 | 75 | 75 | 75 | |
Running Speed | 25 | 25 | 25 | 20 | 20 | 20 | 20 | 20 | 20 | 20 | 20 | 20 | 18 | |
Motor Power | 1 | 1.2 | 2 | 2.2 | 3 | 3.5 | 4 | 5 | 6.3 | 8 | 10 | 15 | 15 | |
Battery Capacity | 180 | 180 | 160 | 180 | 180 | 250 | 250 | 300 | 330 | 400 | 400 | 440 | 600 | |
Battery Voltage | 24 | 36 | 48 | 48 | 48 | 48 | 48 | 48 | 48 | 48 | 72 | 72 | 72 | |
Running Time When Full Load | 4.32 | 5.4 | 4.8 | 4.3 | 4 | 4 | 3.5 | 3.6 | 3.3 | 3 | 3.6 | 3.2 | 2.9 | |
Max Wheel Load | 14.4 | 25.8 | 42.6 | 64.5 | 77.7 | 94.5 | 110.4 | 142.8 | 174 | 221.4 | 278.4 | 343.8 | 265.2 | |
Reference Weight | 2.8 | 3.6 | 4.2 | 5.5 | 5.9 | 6.5 | 6.8 | 7.6 | 8 | 10.8 | 12.8 | 14.6 | 26.8 | |
Recommended Rail Model | P15 | P18 | P18 | P24 | P24 | P38 | P38 | P43 | P43 | P50 | P50 | QU100 | QU100 |
Product Name | Model No. | Power Supply Mode | Load Capacity | Usage |
Rail Transfer Cart | KPD | Conductor Rail | Load range 1-500ton, can be customized per client demand | Ordinary goods,such as steel plate, workpiece,equipment etc special goods,such as coil. column,ladle etc |
Battery Powered Transfer Car | KPX | Battery | ||
Motorized Transfer Trolley | KPJ | Cable Drum | ||
Busbar Powered Handling Cart | KPC | Busbar | ||
Towed Rail Trailer | KP | Tractor | 1-500t | |
Steerable Towed Car | BWT | Tractor | Load range 1-500t, less than 20t, cement floor is ok. More than 20t,steel floor is demanded. | |
Trackless Handling Machine | BWP | Battery |
These points we need to learn: |
1.The load capacity of the transfer cart is ( ) ton. 2.The table size is ( ) mm (L) *( ) mm (W)*( ) mm (H). 3.The voltage is ( ) V,( ) HZ, 3 phase. 4.The running time is ( ) hours per day. 5.The running distance is ( ) m per time. 6.The transfer cart runs on the rails or common floor? 7.Whether exist turning? 8.Whether has other special requirement? |
![]() |
