    High - Rigidity Vertical Machine Center , CNC Milling Machine For Making Molds

    Ask Lasest Price
    Brand Name : JOINT
    Model Number : VMC1270
    Certification : ISO 9001:2015
    Price : NEGOTIATION
    Payment Terms : TT/LC/DA/DP
    Supply Ability : 1000 SETS/YEAR
    Delivery Time : NEGOTIATION
    • Product Details
    • Company Profile

    High - Rigidity Vertical Machine Center , CNC Milling Machine For Making Molds

    CNC Machine Center VMC1270




    1. X,Y,Z Axes slide way are quenched and fixed to mould rail.

    2. High-rigidity machine body ensure cutting requirements can be met.

    3. Coupling, spindle bearing, spindle, ball screw, linear slide way, tool magazine,

    unclamping cylinder and other key parts are imported from Germany,Japan and


    Taiwan top brands to ensure high quality and high precision.

    4. Complete product model,from 540 to 1890,suitable for various small to medium


    mould processing.

    5. Modular configuration,can provide customized options to meet different customers


    processing needs: Spindle water coolant, Gear type spindle-case,12000-15000


    rpm/min direct connection spindle.

    6. This machine center focuses on mould processing,it also suits mechanic parts processing.

    7. In this serie models above 1580 employ temperature control technique (our patent)


    to ensure the stability and accuracy for long-hour processing.




    1. Taiwan famous brand high speed and high precision spindle.


    2. Tool magazine optional


    3. High strength resin sand casting.


    4. NSK bearing imported from Japan


    5. Automatic intermittent lubricate system


    6. Fully enclosed cover


    7. Fanuc, Simens, Mitsubishi, Syntec CNC control system


    ModelUnitVMC1270
    TravelX axismm1200
    Y axismm700
    Z axismm600
    Distance between spindle and tablemm150-750
    Working tableTable sizemm1360*700
    Max. Load of tableKg1000
    T slotPcs-mm-mm5-18-152.5
    Positioning accuracyX/Y/Z axismm0.01/0.008/0.008
    Repeated positioning accuracyX/Y/Z axismm0.008/0.006/0.006
    SpindleSpindle rotation speedRpm8000
    Spindle taperBT50
    DiametermmΦ155
    Rivet modelBT40 45°
    Rapid feedX/Y/Z axism/min15/15/12
    Cutting feedX/Y/Z axism/min8
    Tool magazineUmbrella typeSizeTools20
    Too changing time (T-T)Sec6
    Max. diameter/ length/weight of toolmm134/250/15

    Max tool diameter

    (no tool adjacent)

    mm185
    Arm typeSizeTools24
    Tool changing time (T-T)sec3.5s
    Max. diameter/ /length/weight of toolmm110/200/15

    Max tool diameter

    (no tool adjacent)

    mm200
    Total capacity of electricKVA35
    Weight of machine

    Kg

    9800
    Dimensionmm3560*3300*3100



    Fanuc Controller system

    8000Rpm spindle

    Full enclosed cover

    Spindle encoder position system

    Three axis inner encoder feedback system

    Auto lubrication system

    Pneumatic system

    RS 232 Interface

    Operation unit

    RS232 Interface +working light

    Tool and tool box


    Siemens controller or other controller system

    Spindle oil coolant

    Heat exchanger

    Umbrella type tool magazine

    Arm type tool magazine

    Screw type auto conveyor

    Chain type tool magazine

    4 Axis rotary table

    Ring spray spindle
