    3 - 5 Axis Big Metal Vertical Machine Center 8000rpm Spindle Speed VMC-1890

    Ask Lasest Price
    Brand Name : JOINT
    Model Number : VMC-1890
    Certification : ISO 9001:2015
    Price : NEGOTIATION
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 1000 SETS/YEAR
    Delivery Time : NEGOTIATION
    • Product Details
    • Company Profile

    3 - 5 Axis Big Metal Vertical Machine Center 8000rpm Spindle Speed VMC-1890

    Three axis box way CNC Machine Center VMC1890




    1. X,Y,Z Axes slide way are quenched and fixed to mould rail.

    2. High-rigidity machine body ensure cutting requirements can be met.

    3. Coupling, spindle bearing, spindle, ball screw, linear slide way, tool magazine,

    unclamping cylinder and other key parts are imported from Germany,Japan and


    Taiwan top brands to ensure high quality and high precision.

    4. Complete product model,from 540 to 1890,suitable for various small to medium


    mould processing.

    5. Modular configuration,can provide customized options to meet different


    customers processing needs: Spindle water coolant, Gear type spindle-


    case,12000-15000 rpm/min direct connection spindle.

    6. This machine center focuses on mould processing,it also suits mechanic parts

    processing.

    7. In this serie models above 1580 employ temperature control technique (our


    patent) to ensure the stability and accuracy for long-hour processing.





    1. Taiwan famous brand high speed and high precision spindle.


    2. Tool magazine optional


    3. High strength resin sand casting.


    4. NSK bearing imported from Japan


    5. Automatic intermittent lubricate system


    6. Fully enclosed cover


    7. Fanuc, Simens, Mitsubishi, Syntec CNC control system


    ModelUnitVMC-1890
    TravelX axismm1800
    Y axismm900
    Z axismm680
    Distance between spindle and tablemm160-840
    Working tableTable sizemm2000*900
    Max. Load of tableKg1600
    T slotPcs-mm-mm5-22-165
    Positioning accuracyX/Y/Z axismm0.08/0.008/0.008
    Repeated positioning accuracyX/Y/Z axismm0.006/0.006/0.006
    SpindleSpindle rotation speedRpm8000
    Spindle taperBT50
    DiametermmΦ190
    Rivet modelBT40 45°
    Rapid feedX/Y/Z axism/min12/12/10
    Cutting feedX/Y/Z axism/min8
    Tool magazineUmbrella typeSizeTools20
    Too changing time (T-T)Sec6
    Max. diameter/ length/weight of toolmm134/250/15

    Max tool diameter

    (no tool adjacent)

    mm185
    Arm typeSizeTools24
    Tool changing time (T-T)sec3.5s
    Max. diameter/ /length/weight of toolmm110/200/15

    Max tool diameter

    (no tool adjacent)

    mm200
    Weight of machine

    Kg

    13500
    Dimensionmm4860*4300*3600


    1. Fanuc MF(5) Controller system 2. 8000Rpm spindle

    3. Full enclosed cover 4.Spindle encoder position system

    5. Three axis inner encoder feedback system 6. Auto lubrication system

    7. Pneumatic system 8. RS 232 Interface

    9. Operation unit 10. Working light

    11. Tool and tool box
