Npack Full Automatic Wine Liquor Spray Perfume Bottle Capping Machine with PLC Control

    Buy cheap Npack Full Automatic Wine Liquor Spray Perfume Bottle Capping Machine with PLC Control from wholesalers

    Buy cheap Npack Full Automatic Wine Liquor Spray Perfume Bottle Capping Machine with PLC Control from wholesalers
    • Buy cheap Npack Full Automatic Wine Liquor Spray Perfume Bottle Capping Machine with PLC Control from wholesalers
    • Buy cheap Npack Full Automatic Wine Liquor Spray Perfume Bottle Capping Machine with PLC Control from wholesalers
    • Buy cheap Npack Full Automatic Wine Liquor Spray Perfume Bottle Capping Machine with PLC Control from wholesalers
    • Buy cheap Npack Full Automatic Wine Liquor Spray Perfume Bottle Capping Machine with PLC Control from wholesalers
    • Buy cheap Npack Full Automatic Wine Liquor Spray Perfume Bottle Capping Machine with PLC Control from wholesalers
    • Buy cheap Npack Full Automatic Wine Liquor Spray Perfume Bottle Capping Machine with PLC Control from wholesalers

    Npack Full Automatic Wine Liquor Spray Perfume Bottle Capping Machine with PLC Control

    Ask Lasest Price
    Certification : CE ISO SGS
    Brand Name : N PACK
    Model Number : NP-LC
    Price : 9000USD/set to 50000USD/set
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 60-80bpm
    Delivery Time : 40 working days
    • Product Details
    • Company Profile

    Npack Full Automatic Wine Liquor Spray Perfume Bottle Capping Machine with PLC Control

    Automatic Linear Spray trigger Capping Machine

    Automatic Wine Liquor Spray Perfume Bottle Screw Capping Sealing Machine

    The NP-LC automatic capper machine is specifically designed for capping trigger pump spray caps with long and soft tubes . This advanced linear type machine incorporates a spindle screw mechanism and features a cap elevator that ensures the timely supply of trigger pump caps. It is capable of accurately passing trigger pump caps and placing them into bottles with precision. Additionally, the NP-LC automatic capper machine is equipped with a CE Certificate, ensuring compliance with European safety standards. This machine is particularly suitable for packaging liquid detergent in the daily chemical industries, providing a reliable and efficient solution for various bottling needs.

    MAIN FEATURE

    1. The machine is equipped with variable speed AC motors, allowing for precise control and adjustment to meet different production requirements.
    2. It features spindle wheels adjustment knobs, along with lock nut hand wheels, ensuring easy and secure adjustments for optimal performance.
    3. A meter index is included for easy mechanical adjustment, enabling quick and accurate setup changes without the need for specialized tools.
    4. The design eliminates the need for change parts for a wide range of containers, enhancing versatility and reducing operational costs.
    5. The comprehensive universal cap chute and escapement system is designed to handle various cap types efficiently, ensuring reliable and consistent capping.
    6. With a 2-layer bottle clamping belt, the machine is suitable for containers of various shapes and sizes, providing stability and accuracy during the capping process.


    Product Parameters

    Name/ModelNP-LC Automatic linear spindle capping machine
    Capacity0-200b/min (Subject to bottle and cap)
    Cap DiameterΦ20-120mm
    Bottle Height40-460mm
    Demensions1060*896*1620mm
    VoltageAC220V 50/60Hz
    Power1600W
    weight500KG
    Cap Feeding SystemElevator Feeder

    Product Details

    Automatic Wine Liquor Spray Perfume Bottle Screw Capping Sealing Machine
    6 Wheels
    1. Each wheels speed is indivadually adjustable, requency controlling
    2. The wheels can run in opposite direction to make cap fitting the bottles well if necessary
    3. Wheels are made of soft material to prevent caps from damage
    4. Wheels are horizontally adjustable for different sizes of caps
    5. Wheels are vertically adjustable for bottles of different height
    6. Each wheels driven by one motor

    Two-layer Bottle Clamp Belt
    The double belts height is adjustable to fit differnet sizes bottles.and the angle is adjustable according to the bottle shape, more stable. Speed is frenquecy contolled to match the conveyor and capping speed

    Automatic Wine Liquor Spray Perfume Bottle Screw Capping Sealing Machine
    Automatic Wine Liquor Spray Perfume Bottle Screw Capping Sealing Machine
    Motors

    1. There are 6 motors for the 6 capping wheels, and the motors can be changed to servo motors for adjustable torque if the customer needs.
    2. There are 2 motors for the bottle clamping belt.
    3. There is 1 motor for adjusting the machine height up and down.
    4. The capping torque is adjustable as an option.


    Product Application

    Automatic Wine Liquor Spray Perfume Bottle Screw Capping Sealing Machine
