    8 Port Gigabit Managed Network Switch Realtek Based AC Input SFP Fiber Uplink

    Ask Lasest Price
    Brand Name : Olycom
    Model Number : OM280GW
    Certification : CE RoHS FCC ISO9001
    Price : negotiable
    Payment Terms : T/T, PayPal
    Supply Ability : 2000Pcs per month
    Delivery Time : 4~8 working days
    • Product Details
    • Company Profile

    8 Port Gigabit Managed Network Switch Realtek Based AC Input SFP Fiber Uplink

    10 Port Full Gigabit 8 Port Network Managed Fiber Switch

    Features of 8 Port Managed Switch


    • 8 x 10/100/1000Mbps auto-sensing Ports, 2x 1000Mbps SFP Ports, 1 x Console Port;
    • Support IEEE802.3/IEEE802.3u/IEEE802.3ab/IEEE802.3z, store-and-forward;
    • Flow control mode: full-duplex adopts IEEE 802.3x standard, half-duplex adopts Back pressure standard；
    • Support port auto flip (Auto MDI/MDIX)；
    • Panel indicator monitoring the status and help failure analysis;
    • Support 802.1x port authentication, support AAA authentication, support TACACS+ authentication;
    • Support WEB, TELNET, CLI, SSH, SNMP, RMON management;
    • Surge Protection: General 4KV(level B), ESD 8KV air, 6KV contact(level C)

    Specification of Gigabit Network Switch


    I/O Interface
    PowerAC 100-240 V
    Ethernet

    8*10/100/1000Mbps Ethernet Port

    2*1000Mbps SFP Port

    1*Console Port

    Performance
    Bandwidth20Gbps (non-blocking)
    Packet Forwarding rate14.88Mpps
    Packet Buffer4Mbit
    Memory Capacity128Mbyte
    Flash Capacity16Mbyte
    MAC Address8K
    VLANsVLAN range 1-4094, with a maximum active VLAN of 256
    Jumbo Frame10Kbytes
    Transfer ModeStore and forward
    Standard
    Network protocol

    IEEE802.3: 10Base-T

    IEEE802.3u :100Base-TX

    IEEE802.3ab: 1000Base-TX

    IEEE802.3z :1000Base-FX

    IEEE 802.3x: Flow control

    IEEE 802.1ab: LLDP/LLDP-MED (Link Layer Discovery Protocol)

    IEEE 802.1p: LAN Layer QoS/CoS Protocol Traffic Prioritization(Multicast filtering function)

    IEEE 802.1q: VLAN Bridge Operation

    IEEE 802.1x: Client/Server Access Control and Authentication Protocol

    IEEE 802.3ad: Standard method for performing link aggregation

    IEEE 802.1d: STP

    IEEE 802.1s: MSTP

    IEEE 802.1w: RSTP

    Industry Standard

    EMS: EN61000-4-2 (ESD).

    EN61000-4-5 (Surge)

    Network Medium


    10Base-T : Cat3. 4. 5 or above UTP(≤100m)

    100Base-TX : Cat5 or above UTP(≤100m)

    1000Base-TX : Cat5 or above UTP(≤100m)

    optical characteristics


    multi mode: 850/1310nm (0-2KM)

    Single mode: 1310/1550/1490nm(0-120KM)

    Protection
    Security CertificateCE. FCC. RoHS

    Indication
    LED IndicatorsPWR. SYS. Link. ACT
    Mechanical
    Structure Size

    Product Size: 268*181*44mm

    Package Size: 312*262*84mm

    Product Net-Weight: 1.01KG

    Product Gross-Weight: 1.54KG

    Packing Info

    MEAS: 540*435*332mm

    Packing Qty: 10PCS

    Packing weight: 16.4KG

    Power Voltage

    Power Input Voltage: AC 100-240 V

    Power Output: 12V2A

    powerMaximum 24W

    Software Function


    L3 Function
    IPv4IPv4 VLAN Interface
    IPv4 Static Routes
    ARP
    IPv6IPv6 VLAN Interface
    IPv6 Static Routes
    IPv6 ND
    L2 Function
    PortPort Switch
    Port Description
    Port Speed
    Port Duplex
    Port Flow Control
    Jumbo, Up to 10K
    EEE
    Fiber Module(DDM)
    Link AggregationSupports load balance policy;
    Base on MAC and IP-MAC
    Static and Dynamic Group
    Supports LACP
    Up to 8 groups
    Storm ControlBoardcast
    Unknown Multicast
    Unknown Unicast
    Port MirroringOne to one monitor
    Many to one monitor
    Ingress/Egress/Both
    Up to 4 session groups
    Port SecurityMAC Address Constraints
    Port Security MAC Address
    Protect/Restrict/Shutdown
    Port Isolation
    Port Rate-limit
    Loopback Detection
    VLANAccess/Trunk/Hybrid
    VLAN Tunnel (Q-in-Q Tunnel)
    Congurable VID from 1 - 4094;
    Max. 256 static VLAN groups
    Voice VLAN
    MAC VLAN
    Surveillance VLAN
    Protocol VLAN
    GVRP
    MAC AddressDynamic Address
    Static Address
    Filtering Address
    Spnning Tree ProtocolSTP/RSTP/MSTP
    BPDU Filter
    BPDU Guard
    Edge Port
    LLDPLLDP
    LLDP MED
    MulticastIGMP Snnoping
    IGMP V1/V2/V3
    Router Port
    Static IGMP group address
    IGMP groups filtering
    Querier
    MLD Snooping
    MVR
    QoSTraffic classification based, Strict priority and WRR
    Port Priority
    802.1P Priority
    IP TOS Priority
    IP DSCP Priority
    Supports up to 8 queues per port
    Priority Remarking
    Services
    DHCPDHCP Server
    IP Pool
    Static Binding
    DHCP Relay
    Access ProtocolHTTP
    HTTPS
    Telnet
    SSHv2
    Manager ACL
    Session Timeout
    Password Retry Count
    Silent Time
    Security
    AAARADIUS
    TACACS+
    802.1X
    Base on port/MAC/local/WEB
    DHCP SnoopingGlobal/VLAN
    Option 82
    Circuit ID
    IP Source Guard
    Dynamic ARP Inspection
    DoS
    ACLMAC ACL
    IPv4 ACL
    IPv6 ACL
    Diagnostics
    SyslogLogging Message
    Remote Server
    Ping
    Traceroute
    Copper Test
    UDLD
    Management
    Manager AccessConsole
    HTTP/HTTPS
    Telnet
    SSH
    SNMP
    Manager IPStatic Address
    DHCP Client
    Supports IPv4 and IPv6 address
    Manager VLAN
    DNS
    Time SynchronizationSNTP
    Manual Time
    SNMPV1/V2C/V3
    Community
    V3 User
    Group
    Trap Host
    SNMP MIBRFC 1213 MIB-II
    RFC 1493 Bridge MIB
    RFC 1643 Ethernet MIB
    RFC 2819 RMON MIB (Groups 1, 2, 3 and 9)
    RFC 2863 Interface MIB
    LLDP
    Private MIB
    RMONStatistics
    History
    Event
    Alarm
    User
    FirmwareFirmware Upgarde
    ConfigurationUpload and download
    Save
    Restart
    Factory Defaults
    Standards Compliance
    IEEE 802.3x flow control and back pressure
    IEEE 802.3ad port trunk with LACP
    IEEE 802.1D Spanning Tree Protocol
    IEEE 802.1w Rapid Spanning Tree Protocol
    IEEE 802.1s Multiple Spanning Tree Protocol
    IEEE 802.1p Class of Service
    IEEE 802.1Q VLAN tagging
    IEEE 802.1x Port Authentication Network Control
    IEEE 802.1ab LLDP
    RFC 768 UDP
    RFC 793 TFTP
    RFC 791 IP
    RFC 792 ICMP
    RFC 2068 HTTP
    RFC 1112 IGMP v1
    RFC 2236 IGMP v2
    RFC 3376 IGMP v3
    RFC 2710 MLD v1
    FRC 3810 MLD v2

    Application


    • Metro Optical Broadband Network: Data network operators such as telecommunications, cable TV, and network system integration,etc.
    • Broadband private network: Suitable for financial, government, oil, railway, electric power, public security, transportation, education and other industries
    • Multimedia transmission: Integrated transmission of images, voice and data, suitable for remote teaching, conference TV, videophone and other applications
    • Real-time monitoring: Simultaneous transmission of real-time control signals, images and data
