48 Port Gigabit L3 Managed Network Switch With 10G Fiber Uplinks Realtek Based

Name: 48 Port Gigabit L3 Managed Network Switch With 10G Fiber Uplinks Realtek Based
Brand: Olycom
Price: 1 USD

Ask Lasest Price
Brand Name :	Olycom
Model Number :	OM4X4800GW
Certification :	CE FCC ISO9001
Price :	Negotiable
Payment Terms :	T/T, PayPal
Supply Ability :	1000Pcs per month
Delivery Time :	5~8 working days

Add to Cart

Product Details
Company Profile

48 Port Gigabit L3 Managed Network Switch With 10G Fiber Uplinks Realtek Based

Olycom 52-Port Gigabit Smart Managed Switch with 10G Uplinks

Key Features of L3 Managed Switch

Support IEEE 802.1d,IEEE 802.1w,IEEE 802.1s,IEEE 802.1p,IEEE 802.3,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z,IEEE 802.3ab,IEEE 802.3ae standards ;
L3 management, support DHCP Server, QoS, ACL, SNMP V1/V2/V3, IGMP Snooping v1/v2；
Support STP/RSTP/MSTP (ERPS), Support loop detection and self-healing, support remote loopback monitoring and control(802.3ah OAM); Support IPV4/IPV6, RIP, OSPF
Support multiple VLAN division, MAC VLAN, Protocol VLAN, Private VLAN;
Support IP address + MAC address + VLAN+Port binding, DHCP Snooping, support IP source and DAI protection;
Surge Protection: General 6KV(level B), ESD 8KV air, 6KV contact(level C)

Specification of 10G Fiber Switch

Input/output Port
AC INPUT	AC100-240V,50/60Hz
Ethernet Port	48 * 10/100/1000Mbps RJ45 Port 4 * 10G SFP+ Port 1 * RJ45 Console Port 1 * USB Port
Performance
Bandwidth	176Gbps
Packet Buffer Memory	131Mpps
DDR SDRAM	512MByte
Flash Memory	32MByte
Package Cache	16Mbit
MAC Address	32K
Jumbo frame	10Kbytes
VLANs	VLAN range 1-4094, with a maximum active VLAN of 4K
Standard
Network Protocols	IEEE 802.3: Ethernet MAC Protocol IEEE 802.3i: 10BASE-T Ethernet IEEE 802.3u: 100BASE-TX Fast Ethernet IEEE 802.3ab: 1000BASE-T Gigabit Ethernet IEEE 802.3z: 1000BASE-X Gigabit Ethernet (optical fiber) IEEE 802.3ae: 10G Ethernet (optical fiber) IEEE 802.3az: Energy Efficient Ethernet IEEE 802.3ad: Standard method for performing link aggregation IEEE 802.3x: Flow control IEEE 802.1ab: LLDP/LLDP-MED (Link Layer Discovery Protocol) IEEE 802.1p: LAN Layer QoS/CoS Protocol Traffic Prioritization(Multicast filtering function) IEEE 802.1q: VLAN Bridge Operation IEEE 802.1x: Client/Server Access Control and Authentication Protocol IEEE 802.1d: STP IEEE 802.1s: MSTP IEEE 802.1w: RSTP
Industry Standard	EMS: EN61000-4-2 (ESD) EN61000-4-5 (Surge)
Network Media	10BASE-T: Cat3,4,5 or above UTP(≤100 M) 100BASE-TX: Cat5 or above UTP(≤100 M) 1000BASE-TX: Cat5 or above UTP(≤100 M) Multi-mode Fiber: 50/125,62.5/125,100/140um Single-mode Fiber: 8/125,8.7/125,9/125,10/125um
Certification
Safety Certificate	CE,FCC,RoHS
Environmental Standards
Working Environment	Operating temperature: -10~50°C Storage temperature: -40~70°C Operating Humidity: 10%~90%, No condensation Storage Humidity: 5%~95%, No condensation
Function Indication
Indicator Light	PWR(Power indicator), SYS(System lights), Link/ACT(Link light/data light)

Software Function

L3 Function
IPv4	IPv4 VLAN Interface
	IPv4 Static Routes
	ARP
IPv6	IPv6 VLAN Interface
	IPv6 Static Routes
	IPv6 ND
RIP	V1/V2
OSPF	Router-ID
	Authentication
	v2

L2 Function
Port	Port Switch
	Port Description
	Port Speed
	Port Duplex
	Port Flow Control
	Jumbo, Up to 10K
	Support 10G/2.5G (2023.3.2)
	Fiber Module(DDM)
Link Aggregation	Supports load balance policy; Base on MAC and IP-MAC
	Static and Dynamic Group
	Supports LACP
	Up to 8 groups
Storm Control	Boardcast
	Unknown Multicast
	Unknown Unicast
Port Mirroring	One to one monitor
	Many to one monitor
	Ingress/Egress/Both
	Up to 4 session groups
Port Security	MAC Address Constraints
	Port Security MAC Address
	Protect/Restrict/Shutdown
Port Isolation
Port Rate-limit
Loopback Detection
VLAN	Access/Trunk/Hybrid
	VLAN Tunnel (Q-in-Q Tunnel)
	Congurable VID from 1 - 4094; Max. 4K static VLAN groups
	Voice VLAN
	MAC VLAN
	Surveillance VLAN
	Protocol VLAN
	GVRP
MAC Address	Dynamic Address
	Static Address
	Filtering Address
Spnning Tree Protocol	STP/RSTP/MSTP
	BPDU Filter
	BPDU Guard
	Edge Port
ERPS	Only SFP port
	ALL Port
LLDP	LLDP
	LLDP MED
Multicast	IGMP Snnoping
	IGMP V1/V2/V3
	Router Port
	Static IGMP group address
	IGMP groups filtering
	Querier
	MLD Snooping
	MVR
QoS	Traffic classification based, Strict priority and WRR
	Port Priority
	802.1P Priority
	IP TOS Priority
	IP DSCP Priority
	Supports up to 8 queues per port
	Priority Remarking
Services
DHCP	DHCP Server
	IP Pool
	Static Binding
	DHCP Relay
	Option 43
Access Protocol	HTTP
	HTTPS
	Telnet
	SSHv2
	Manager ACL
	Session Timeout
	Password Retry Count
	Silent Time
Security
AAA	RADIUS
	TACACS+
	802.1X
	Base on port/MAC/local/WEB
DHCP Snooping	Global/VLAN
	Option 82
	Circuit ID
IP Source Guard
Dynamic ARP Inspection
DoS
ACL	MAC ACL
	IPv4 ACL
	IPv6 ACL
Diagnostics
Syslog	Logging Message
	Remote Server
Ping
Traceroute
Copper Test
UDLD
Management
Manager Access	Console
	HTTP/HTTPS
	Telnet
	SSH
	SNMP
Manager IP	Static Address
	DHCP Client
	Supports IPv4 and IPv6 address
	Manager VLAN
	DNS
Time Synchronization	SNTP
	Manual Time
SNMP	V1/V2C/V3
	Community
	V3 User
	Group
	Trap Host
SNMP MIB	RFC 1213 MIB-II
	RFC 1493 Bridge MIB
	RFC 1643 Ethernet MIB
	RFC 2819 RMON MIB (Groups 1, 2, 3 and 9)
	RFC 2863 Interface MIB
	LLDP
	Private MIB
RMON	Statistics
	History
	Event
	Alarm
User
Firmware	Double Image; Swap between Active and Alternate firmware image.
	Firmware Upgarde
Configuration	Upload and download
	Upload and download via USB interface
Save
Restart
Factory Defaults
Standards Compliance
IEEE 802.3x flow control and back pressure
IEEE 802.3ad port trunk with LACP
IEEE 802.1D Spanning Tree Protocol
IEEE 802.1w Rapid Spanning Tree Protocol
IEEE 802.1s Multiple Spanning Tree Protocol
IEEE 802.1p Class of Service
IEEE 802.1Q VLAN tagging
IEEE 802.1x Port Authentication Network Control
IEEE 802.1ab LLDP
RFC 768 UDP
RFC 793 TFTP
RFC 791 IP
RFC 792 ICMP
RFC 2068 HTTP
RFC 1112 IGMP v1
RFC 2236 IGMP v2
RFC 3376 IGMP v3
RFC 2710 MLD v1
FRC 3810 MLD v2
RFC 2328 OSPF v2

Dimension

Physical Specifications
Product Information	Product Dimensions: 44028044mm Package Dimensions: 50036585mm Product N.W: 3.87KG Product G.W: 4.70KG
Packing Information	Carton Dimensions: 520445385mm Packing Quantity: 5psc Packing weight: 24.6KG
Voltage	Input Voltage: AC100-240V/50-60Hz Power supply: 12V8A
Power Consumption	Maximum 46W
Packing list	Ethernet switch: 1 Set Instruction manual: 1 PCS Certificate, warranty card: 1 PCS Power cord: 1PCS Serial cable: 1PCS Rack ear: 1 Pair

Accessories

OSPL1G05D	1000BASE-SX
OSPL1G06D	1000BASE-SX (1310nm)
OSPL1G20D	1000BASE-LX
OSPL1G40D	1000BASE-EX
OSBL1G20D-35	1000BASE-BX-U (TX 1310 RX1550)
OSBL1G20D-53	1000BASE-BX-D (TX 1550 RX1310)
OSPLXG05D	10GBASE-SR
OSPLXG06D	10GBASE-SR (1310nm)
OSPLXG10D	10GBASE-LR
OSPLXG40D	10GBASE-ER
OSBLXG20D-23	10GBASE-BX-U (TX 1270 RX1330)
OSBLXG20D-32	10GBASE-BX-U (TX 1330 RX1270)
