1250A 3 Phase Generator Automatic Changeover Switch ATS CCC

    Buy cheap 1250A 3 Phase Generator  Automatic Changeover Switch ATS CCC from wholesalers

    Buy cheap 1250A 3 Phase Generator  Automatic Changeover Switch ATS CCC from wholesalers
    • Buy cheap 1250A 3 Phase Generator  Automatic Changeover Switch ATS CCC from wholesalers
    • Buy cheap 1250A 3 Phase Generator  Automatic Changeover Switch ATS CCC from wholesalers

    1250A 3 Phase Generator Automatic Changeover Switch ATS CCC

    Ask Lasest Price
    Brand Name : Ai Power
    Model Number : YAT1250
    Certification : CE, ISO
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 200 units per month
    Delivery Time : 7 to 10 days
    • Product Details
    • Company Profile

    1250A 3 Phase Generator Automatic Changeover Switch ATS CCC

    1250A 3p/4p ATS Automatic Transfer Switch China Famous Low Voltage Brand CCC Ce


    YAT series Automatic transfer switch mainly used for distribution or electromotor network, wihich under voltage 400V, rated voltage DC 220V,

    Rated current 63A-3200A.Main power and standby power or mutual standby power change over system or city power and generator group overload switch-over. At the same time, it can operated under un-frequency on and off circuit act as disconnector. Widely used at the field of important power supply site, which transport, distribution power supply system and automatization system. For fire protection hospital,bank,building,etc, where doesn't allow power off.


    ATS Specifications:


    Manufacturer

    XIAMEN AI POWER TECHNOLOGY CO., LTD.

    ATS module Brand

    Aisikai

    ATS model

    YAT1250

    Capacity(A)

    1250

    Voltage(V)

    400V, 380V, 220V, 480V

    Poles

    4 poles

    Type

    Double Power

    Type

    PC


    Agreed thermal current Ith

    1250A

    Rated insulation voltage Ui

    1000V

    Rated impulse withstand voltage Uimp

    12kV

    Rated voltage of the switch copper

    AC 440V

    Rated work current Ie

    1250A

    Rated connection capability

    10 Ie

    Rated breaking capability

    10 Ie

    Rated conditional short-circuit current

    100kA

    Rated short-time withstand current Is

    50 kA

    Trasfer time 1 - 2 or 2 - 1

    1.2 s

    Control voltage of the switch motor

    DC24V AC220V AC280V

    1



    SKT series automatic transfer switch is the most advanced third generation ATS. It's of PC Class (one-piece structure). SKT standard type is able to operate the current from 20A to 3200A.

    Its use category reaches the highest AC-33A, is suitable for reliable


    STANDARDS


    IEC60947-6-1

    GB/T14048.11


    FEATURES


    • Voltage and Switch Working Conditions Indications Using LED

    • External Replaceable Fuses, Easy For Maintenance

    • Built-in Microprogrammed Control Unit Realise Voltage Dectection Function

    • Silver Plated High Purity Copper Bars

    • Brige Connect Structure on Load Side

    • Three-Sections Design (I – 0 – II), Zero Position For Dual Powers Off

    • Pluggable Wiring Terminals

    • Mechanical Interlock & Electrical Interlock



    FAQ

    1.Are you a factory or trading company?

    A: We are a factory.

    2.What is the material of your products?

    A: Iron, Steel, plastic, etc.

    3.How about quality control in your factory?

    A: AI people are always paying great attentions to quality controlling from the beginning to the end.

    4.How about your guarantee?

    A: Our warranty period is 1 year or 1000 running hours, whichever comes first.
