660V 2 Pole Aisikai Automatic Phase Changeover Switch ISO9001

Name: 660V 2 Pole Aisikai Automatic Phase Changeover Switch ISO9001
Brand: Ai Power
Price: 1 USD

Ask Lasest Price
Brand Name :	Ai Power
Model Number :	YAT1000
Certification :	CE, ISO
Payment Terms :	L/C, T/T, Western Union, MoneyGram
Supply Ability :	200 units per month
Delivery Time :	7 to 10 days

Add to Cart

Product Details
Company Profile

660V 2 Pole Aisikai Automatic Phase Changeover Switch ISO9001

3Phase 2/3/4Poles ats automatic transfer switch controller 1000A for generator

Ai Power YAT series automatic transfer switch(ATS) adopt high quality and reliable switch module which is designed for emergency power supply. It can transfer the load between mains power and mains power or between mains and generator in few seconds. It can automatically detect the voltage and frequency of mains power or generator power timely. The ATS has an intelligent integrated design with PC pole and zero position function. It has larger isolation distance to withstand higher impact voltage above 8KV. The technology and performance of the ATS conform with standard of IEC60947-6-1, GB14048.11-2002.

ATS Specifications:

Manufacturer	XIAMEN AI POWER TECHNOLOGY CO., LTD.
ATS module Brand	Aisikai
ATS model	YAT1000
Capacity(A)	400
Voltage(V)	400V, 380V, 220V, 480V
Poles	4 poles
Type	Double Power
Type	PC

Agreed thermal current Ith	1000A
Rated insulation voltage Ui	660V
Rated impulse withstand voltage Uimp	6kV
Rated voltage of the switch copper	AC 400V
Rated work current Ie	1250A
Rated connection capability	10 Ie
Rated breaking capability	10 Ie
Rated conditional short-circuit current	100 kA
Rated short-time withstand current Is	9 kA
Trasfer time 1 - 2 or 2 - 1	2.4 s
Control voltage of the switch motor	DC24V AC220V AC280V

Performance

Double complex contact, horizontal and vertical type frame basically, it have come to "Zero" arc(no arc chute);
Reliable machine interlock and elecric interlock, the executive union parts adopt independency overload disconnect switch,
it makes more reliable and safety.
"zero" techinique, can force to set"zero" under emergency situation(break off two ways power supply at the same time).Meet the requirement of the fire protection linkage.
Operate overload disconnect switch change over adopt singless electromotor drive, switch over smooth and reliable, no noise,
little wallop
Operate machine drive motor use only under the executive overload disconnect switch change over instanecus current across, outstanding energy saving.

Perform overload disconnect switch with mechanism interlock device. It ensure the common use, standby power working
reliable and not interference.
Distinct on and off position indicator, padlock function et.c safe realize the isolator between electric power and overload
High security, high automatization, high retiablility, use life more than 8000times

Since established in 2007, AISIKAI has been committed to the manufacture, research, development and marketing of the high-quality electric switch.
AISIKAI has obtained the UKAS ISO9001 Quality Management System and SGS Global Qualified Supplier Authentication.Product lines cover level Ⅰ,Ⅱ,Ⅲ power distribution filed. All products have Chinese Compulsory Certification CCC and European Certification CE. We have several patented technologies, and all products own proprietary intellectual property rights.

SKT ATS used in Generator system, to changeover two power sources. Widely used at the field of important power supply site,which transport, distribution power supply system and automatization system.
For fire protection, hospital, bank, building etc, where doesn't allowed power off.

Factory Overviews

FAQ

1.Are you a factory or trading company?

A: We are a factory.

2.What is the material of your products?

A: Iron, Steel, plastic, etc.

3.How about quality control in your factory?

A: AI people are always paying great attentions to quality controlling from the beginning to the end.

4.How about your guarantee?

A: Our warranty period is 1 year or 1000 running hours, whichever comes first.
