    Geotechnical Investigation Hydraulic Drilling Rig Xy-2

    Ask Lasest Price
    Brand Name : ShiTan
    Model Number : XY-2
    Certification : ISO9001
    Price : Negotiation
    Payment Terms : T/T, Western Union
    Delivery Time : Within 7-12 days
    • Product Details
    • Company Profile

    Geotechnical Investigation Hydraulic Drilling Rig Xy-2

    Geotechnical Investigation Hydraulic Drilling Rig XY-2 Soil Testing Drilling Machine Rig


    XY-2 400 Meters Crawler Mounted Drill Rig Description


    Hydraulic core drilling rig is mainly used for geological general investigation and exploration,kindly of hole in concrete structure,road and tall building foundation exploration,civil wells etc.

    The drilling machine with light weigh,suitable for different working environment,like plain or valley places.Handle rack and hydraulic power syatem keeps the higher efficiency.

    XY-2 400 Meters Crawler Mounted Drill Rig Specifications



    Drill

    Swivel Head

    Drilling depth

    Max.200~400m

    Spindle speed

    60 105 165 228 235 405 638 880 r/min

    Hole diameter

    Max.600m

    Spindle stroke

    550kmm

    Drill rod diameter

    42mm

    Spindle pull-down

    Max.50KN

    Angle range

    0°~360°

    Spindle lifting capacity

    Max. 37KN

    Oil pump

    Water pump

    Model

    YBC-20/125

    Model

    Gear oil pump

    Rated pressure

    8Mpa

    Working pressure

    Max. 10Mpa

    Flow speed

    20ml/r

    Rated speed

    150r/min

    Hoist

    Power(diesel)

    Max. lifting capacity

    212kgs

    Model(diesel engine

    ZS1115

    Hoisting drum revolution

    20.39.85.170r/m

    Rated power

    18.5KW

    Drum diameter

    140mm

    Rated speed

    1800 r/min

    WEIGHT

    AROUND 980kgs

    SIZE

    2330x1050x1620mm


    Drilling rig Applications


    (1)widely used in drilling large diameter blast hole in mining, road, national defence,water conservancy and so on

    (2)necessary drill equipment for prophase surface mine project.


    Drilling rig Characteristics


    (1)light weight, easy portable, suitable for different working environment, like plain or valley places.

    (2)Handle rack, easy operation, safe for body.

    (3)Hydraulic power drilling device, high effiency.

    (4)Fast Drilling speed; horizontal and vertica direction drill.
