    Automatic Sampling 30m Soil Testing Drilling Rig

    Ask Lasest Price
    Brand Name : JINZHOU SHITAN
    Model Number : ST-200
    Certification : ISO
    Price : Negotiation
    Payment Terms : L/C, D/A, D/P, T/T, Western Union
    Supply Ability : 2000 sets per year
    Delivery Time : 7-12 days
    • Product Details
    • Company Profile

    Automatic Sampling 30m Soil Testing Drilling Rig

    Core Sampling Automatic Lifting Rod Collection Soil Test Drilling Machine


    Product Description:


    1. Used for census exploration, geophysical exploration, road and building exploration and blasting drilling and other drilling projects;

    2. According to the different strata of the choice of alloy, steel grit and steel bit drilling;

    3. Can drill 2-9 grade sandy clay and bedrock layer.


    Product Parameter:


    Drilling Rig
    Drilling diameter(mm)75,91,110,130,150,300
    Drilling depth (m)200,150,100,70,50,30
    Drill pipe diameter (mm)42,50
    Drilling angle(°)90~75
    Equipment size(L * B * H)1730 * 860 * 1360 (mm)
    Rig weight (except engine)580
    Mobile device
    Moving length350mm
    Leave distance300mm
    Gyrator
    Spindle speed (four gear) (r/min)115,230,505,1010
    Spindle travel(mm)450
    Spindle no-load lifting maximum moving speed(m/s)0.05
    Spindle no load drop maximum movement speed(m/s)0.067
    Spindle maximum feed pressure(KN)15
    Spindle maximum lifting force(KN)25
    Spindle maximum output torque(KN• m)1.5
    Winch assembly
    Winch maximum lifting force (single rope)20
    Reel speed (r/min)20,39,85,170
    Reel circumferential speed(m/s)0.172, 0.345, 0.738, 1.476
    Reel diameter(mm)140
    Wire rope diameter(mm)9.3
    Wire rope density (m)40
    Brake diameter(mm)278
    Brake band width (mm)50
    Water pump
    Pump typeHorizontal single cylinder double acting
    Maximum displacement (motor)(L/min)95 (77)
    The maximum allowable pressure (Mpa)1.2
    Work pressure (Mpa)0.7
    Cylinder diameter (mm)80
    Piston stroke(mm)100
    Oil pump
    Oil pump typeYBC-20/125
    Nominal pressure (Mpa)12.5
    Rated flow(ml/r)20
    Rated speed(r/min)800-2500
    Diesel engine or motor
    Diesel engine1110
    Rated power (KW)16.2
    Rated speed (r/min)2200
    Rated pressure(Mpa)12.5
    Motor typeY160M - 4
    Rated power (KW)11
    Rated speed (r/min)1460

    Product Feature:


    1. With automatic feeding into the body, high drilling efficiency.

    2. The use of the ball card clamping mechanism instead of chuck, can be implemented without down the bar.

    3. Handle centralized, easy to operate, safe and reliable.

    4. Compact structure, rig, pumps and diesel engines are installed in the same chassis, the occupation of small venues.

    5. Light weight, strong decomposition, easy to move, suitable for plain and mountain work.


    Precautions for courtyard drilling


    1. Consider whether the well depth is reasonable

    We should first investigate whether there are cables, sewers and other facilities under the ground, and avoid unnecessary damage.

    2. Convenience, health and other issues should be considered.

    After drilling the well, find some charcoal and throw it into the well with a bag and press it at the bottom of the well to absorb foreign toxins. After having water, you can put a few small fish down, which is a good way to test the safety of water quality.

    3. The well should not be too deep. It should be above the ground and should be blocked with bricks and stones. It is better to have a cover, so as to prevent dirt from falling in, make people feel safer and avoid unnecessary dangers.
