    PET Bottle CO2 Laser Marking Machine 0-130m/min With Laser Coder

    Ask Lasest Price
    Brand Name : COTAJET
    Model Number : CL500C
    Certification : CE,Rohs,SGS
    Delivery Time : 5-7 work day
    Payment Terms : TT,L/C,Western union
    • Product Details
    • Company Profile

    PET Bottle CO2 Laser Marking Machine 0-130m/min With Laser Coder

    CO2 Laser Marking with laser coder for PET Bottle

    Cotajet CO2 laser marking on water bottle, expiry date on Pet bottle,coding and marking on PET bottle,laser coding on plastic bottles and containers,mark on glass bottle, bottle coding,coding solutions for plastic and rubber parts.


    High-speed marking capability prints up to 2,000 characters per second of text, bar codes, graphics, and other information

    High-resolution marking head delivers high-quality and permanent codes to support product traceability and anti-counterfeiting

    Variety of lenses deliver one of the largest marking areas while options like beam turning unit options simplify integration

    Multiple marking heads and wavelengths provide the flexibility to code a wide range of materials such as plastics, wood, glass, ceramics, and coated metals

    Up to 45,000 hours of laser source life expectancy offers extended operational life, reliable performance, and reduced cost of ownership

    Air-cooled laser source helps reduce maintenance intervals and additional costs

    Main Characters:

    1. CO2 laser marking machines are renowned for their versatility and precision across many applications. Suitable for numerous applications, their ability to mark a wide range of materials, including plastics, glass, and paper, is helpful.

    2. Another benefit of a CO2 laser marker is its permanence. High-energy CO2 laser beams produce long-lasting, readable markings that are immune to fading, abrasion, and corrosion. These durable markings are crucial for applications where adherence to stringent traceability and identification standards is necessary.

    3. Also, CO2 laser marking is a non-contact process, which means there’s minimal wear on the machine and the materials being marked. This feature decreases both material waste and maintenance costs. If these benefits weren't enough, the rapid performance of CO2 laser etching machines also increases output and improves manufacturing operations' efficiency.

    Parameter:


    Item

    Parametertable

    CO2-30W

    CO2-40W

    CO2-60W


    characteristic

    Machine material

    All aluminum sandblasting oxidation

    Laser

    The service life is more than20000-30000 hours

    Laser wavelength

    1060nm

    output power

    ≥38W

    ≥43W

    ≥70W

    Marking speed

    ≤12000mm/s

    controller

    10.2 inch touch controller

    Cooling system

    Air Cooling


    parameter

    Focus lens

    145mm

    Minimum linewidth

    0.03mm

    Repetitionaccuracy

    0.01mm

    Marking range

    110mm*110mm(optinal)

    Number of rows

    Any line within the marking range

    Production line speed

    0~130m/min (depending on the material)


    Software

    Multilingual

    English, Spanish, German, Chinese, Russian, Arabic, etc

    jurisdiction

    Multi user management authority

    operating system

    Linuxsystem

    Inkjet mode

    Static, analog, encoder

    Reserved signal

    Start, print status, finish, fault

    data protection

    With power failure data protection energy

    monitor

    Provide overspeed alarm function

    De crossing

    Automatic removal of intersections

    Coding software

    Single and double machine code sending


    Support type

    typeface

    Chinese and English, numbers, traditional, etc

    file format

    BMP/DXF/HPGL/JPEG/PLT

    bar code

    CODE39,CODE128,CODE126,QR


    Servicing parameters

    Power Supply

    220V/50HZ

    Power consumption

    800W

    Net weight of machine

    45kg+38kg(Bracket)

    Overall dimension

    nose:666mmX165mmX157mm

    environment

    requirement

    External temperature0℃45℃;humidity≤95
