0-0.12" Coaxial Centering Dial Indicator for Precision Measurement in Milling and Testing

0-0.12" Coaxial Centering Dial Indicator for Precision Measurement in Milling and Testing

Quick Detail:

1. Metric dial.

2. For quick centering on milling and boring set-ups.

3. Including 3 straight(internal) feelers and 3 curved(external) feelers.

4. Indicator body completely enclose the indicator to provide more rigidity.

5. Indicator body completely ground finished to minimize runout on the indicator.

6. Supplied in a fitted wood case.

Description:

This is metric measurement coaxial centering dial indicator with 0-3mm measuring range and 0.01mm graduation.

Coaxial indicator provides a simple and accurate method of finding the center on a bore or cylinder of a workpiece or fixture

in a milling machine or lathe. The face of the indicator remains stationary with the help of the stopping rod while the machine

spindle rotates in low RPM. Adjust the table position in both X and Y axis to reduce the travel of the dial indicator.

When the dial hand is stationary, then the center of the location is found.

With high precision, high sensitivity, easy operation and good stability, the coaxial centering dial indicator is an important precision

measurement tool, which is widely used in the fields of machining, assembly and testing, and plays an important role in ensuring

the quality of workpieces and improving production efficiency.

Specification:

Notices:

1. Make sure the coaxial centering dial indicator is properly installed and calibrated.

2. According to the size of the workpiece and the measurement requirements,

adjust the measuring range of the centering table.

3. When in use, vibration and shock of the workpiece or machine tool should be avoided.

4. Keep it clean and avoid dust and dirt that can affect accuracy.

Applications:

The coaxial centering dial indicator mainly used in machine shops and manufacturing settings, used to determine

the center position or axis of the workpiece to ensure machining accuracy.

FAQ:

1) Who are we?

Deko Corporation mainly dedicate to the development, manufacture and marketing of KM brand precision measuring tools

in China mainland.

2) What products do we carry?

Dial indicators, micrometers, calipers, bore gauges, height gauges, dial thickness gauges, depth gauges, bevel protractors,

gauge, blocks, level, etc.

3) What are the terms of trade?

We support FOB, CFR, CIF, EXW.

4) What are the forms of payment?

We accept T/T, L/C, D/A, D/P, PayPal, Western Union.

5) Do we accept customization?

Yes, OEM is available.

6) How about after-sales service?

One year warranty for all kinds of products.

If you find any defective accessories when receive goods, we will ship your news parts or new product to replace.

As an experienced manufacturer, we have very strict calibration and inspection team, you can rest assured of our product quality.
