    RION 0.01deg 1A Mercury Free Tilt Switch Module Level Control Hydraulic Cylinder

    Ask Lasest Price
    Model Number : LCA341
    Brand Name : RION
    Supply Ability : 30000 Unit/Units per Month
    Price : $75.00/Units >=1 Units
    Payment Terms : T/T, L/C
    Delivery Time : 5-10 work days
    • Product Details
    • Company Profile

    RION 0.01deg 1A Mercury Free Tilt Switch Module Level Control Hydraulic Cylinder

    Cheapest Tilt Switch Sensor For Level Control Hydraulic Cylinder


    Description


    LCA341A is RION company integrated control core unit developed a dual axis digital type tilt switch sensor which built-in relay output circuit , application for level safety alarming and platform level detection ...etc related industry field . Alarm threshold value is pre-setable. when the inclination exceed set alarm value, it will output a no contact relay signal(drive current 1A) , to open the valve to control the corresponding hydraulic leg leveling . Product design precision , further compensation on the temperature and linearity , integrated the comprehensive protection function for the short circuit, instant high voltage , polarity ,swell ...etc. Suitable for all kinds of harsh industrial environment.Also adopts industrial-gradeMCU, three proofing PCB board, imported cable, wide temperature metal shell...etc all kinds of measures to improve the industrial level of the product on it’s reliability and stability .


    Feature

    • Single/dual axis
    • Accuracy: refer to parameter
    • RS232 set alarm threshold
    • Replay output
    • Wide working temp.:-40~+85℃
    • Resolution: 0.01°
    • IP67
    • High anti-vibration>2000g
    • Direct lead cable interface
    • Adjustable alarm value
    • zero set function
    • positive/negative output optional
    • DC 9~36V wide Voltage input

    Application

    • Engineering vehicles automatic leveling
    • Railway locomotive monitoring
    • All kinds of engineering machinery angle measurement
    • Oil drilling equipment
    • Underground drill position navigation
    • Navigation attitude measuring
    • Shield pipe jacking application
    • Geological equipment slope monitoring
    • Intelligent excavator/crane /pile machine/drill/mining vehicle/track/fire/ bridge machine

    Technical Data

    Measuring rang

    ±15

    °

    Measuring axis

    X ,Y axis

    Resolution

    0.05

    °

    Absolute accuracy

    0.1

    °

    Long term stability

    0.05

    Zero

    temperature coefficient

    -40~85 ±0.006

    °/℃

    Sensitivity temperature coefficient

    -40~85100

    ppm/

    Power on time

    0.1

    S

    Response time

    0.2

    s

    EMC

    According to EN61000 and GBT17626

    MTBF

    50000 hours/time

    Insulation Resistance

    100M

    Shockproof

    100g@11ms,3Times/Axis(half sinusoid))

    Anti-vibration

    10grms,10~1000Hz

    Protection glass

    IP67

    Cables

    Standard 1M length,wearproof,grease proofing,wide temperature,

    Shielded cables 4*0.4mm2

    Weight

    150g(without cable)

    Electronic Characteristics

    Power supply

    Standard

    9

    12,24

    36

    V

    Alarm output current

    1000

    M A

    Working current

    No-load

    40

    M A

    Working temperature

    -40

    +85

    Store temperature

    -55

    +125
