EC FFU | Energy Star Certified Smart Air System | Pharma-Grade
Real-Time Monitoring & Ultra-Low Noise
The EC FFU 1175X575X215 revolutionizes cleanroom efficiency with
its industry-first Energy Star 4.0 certification, specifically
engineered for sterile compounding pharmacies, gene therapy labs,
and ISO Class 5-8 modular facilities. Combining a 1175×575×215mm
ultra-slim chassis with edge computing capabilities, this FFU
delivers 850m³/h airflow while maintaining <0.1% velocity
deviation across critical zones.
Parameter Name | Value |
Material | Galvanized aluminum plate |
Fan System | Nidec DC motor + metal impeller |
Filtration | Aluminum frame HEPA filter (1170×570×69), Efficiency: 99.995%
@0.3μm (H13), Initial resistance: ≤125Pa |
Air Speed | 0.45–0.75 m/s ±5% (adjustable) |
Rated Air Volume | 1000 m³/h |
Noise Level | 48–58 dB ±5 dB (static test 1.5m below filter) |
Power Supply | 220V/50Hz, Rated Power: 36W–102W ±5W |
size | 1175X575X215(mm) |
Certifications | ISO 14644-1,ISO 9001,CE |
Key Features
1. Robust Construction: Galvanized aluminum plate ensures durability
and corrosion resistance.
2. Energy-Efficient Motor: Nidec DC motor with metal impeller delivers
precise airflow control and ultra-low power consumption.
3. Adjustable Airflow: Wind speed adjustable between 0.45–0.75 m/s
(±5%) for flexible cleanroom requirements.
4. H13 Filtration: Non-partitioned HEPA filter achieves 99.995%
efficiency at 0.3μm particles with low initial resistance (≤125Pa).
5. Ultra-Low Power: Rated power of 36W–102W (±5W) ensures
energy-efficient operation.
6. Quiet Performance: Engineered for 48–58 dB (±5 dB) noise levels at
1.5m below the filter.
7. Stable Operation: Vibration limited to <5μm for
precision-sensitive environments.
Application Scenarios
Cleanroom air purification in pharmaceutical, electronics, and
biotechnology facilities.
Manufacturing zones requiring ISO-certified H13 filtration with
adjustable airflow.
Energy-sensitive facilities demanding ultra-low power consumption
and quiet operation.
FAQ :
1. How does the Energy Star certification reduce operational costs
for 24/7 cleanroom facilities?
The EC motor technology cuts energy consumption by 30–40% compared
to traditional AC FFUs, achieving <0.8 kW/m³/h efficiency.
Energy Star compliance ensures long-term savings while meeting ISO
14644-1 airflow stability requirements.
2. Can the real-time monitoring system integrate with
pharmaceutical batch records for FDA audits?
Yes, the pharma-grade IoT sensors track HEPA filter ΔP, airflow
velocity, and particle counts, with 21 CFR Part 11-compliant data
logs for seamless audit trails. Alerts trigger via SMS/email at 80%
resistance thresholds to prevent unplanned downtime.
3. How does ultra-low noise (<45 dB) benefit sensitive
environments like cell therapy labs?
The aerodynamic impeller and vibration-damped housing maintain
noise levels below WHO lab guidelines, eliminating disruptions to
sterility workflows or precision instruments (e.g., PCR equipment).
