    Uncoil Servo Feeder Machine Straightener Servo Roll Feeder

    Ask Lasest Price
    Brand Name : RILANT
    Model Number : SZWG-1000
    Certification : CE
    Price : Negotiation
    Payment Terms : L/C, T/T
    Supply Ability : 500 sets per month
    Delivery Time : 15 work days
    • Product Details
    • Company Profile

    Uncoil Servo Feeder Machine Straightener Servo Roll Feeder

    High Precision Decoiler Straightener Feeder 3 In 1 Metal Straightener Nc Straightener Feeder


    Features:

    1. A wide range of species, wide range of applications.

    2. Convenient operation, real automation, greatly save labor. Reduce labour intensity.

    3. Compact structure and small space occupation.

    4. leveling/ feeding accuracy is higher, the finished product quality ts good.

    5. Import core components, complete lubrication systems.

    6. With self-test procedures, high reliability.


    Standard equipment:

    Electric Eye Loop Control System

    Feed and Straightener rolls with a hard chrome finished

    Outgoing catenary to assist and Support the material

    Motor power arm hold down device

    Feeding line easily adjusts by advance worm gear screw jacks device

    Uncoiler-inverter Device

    The reading table device

    Coil tip flatness device

    The uncoil contain the butterfly brakes air compressor

    A cluster gear set maximizes transmission of horsepower

    Coil side guide

    Die-high electric conditioning

    LCD touch screen operation system


    Optional equipment:

    Hydraulic Material Feed-in Cart


    ModelUnitNCMF-300NCMF-400NCMF-500NCMF-600NCMF-800NCMF-1000
    Material widthmm50-30050-40050-50050-60050-80050-1000
    Material widthmm0.3-3.20.3-3.20.3-3.20.3-3.20.3-3.20.3-3.2
    Coil IDmm508508508508508508
    Coil ODmm120012001200120012001200
    Max speedm/min16-2416-2416-2416-2416-2416-24
    Feeding lengthmm~500~500~500~500~500~500
    Servo motorkwAC2.9AC2.9AC2.9AC2.9AC2.9AC2.9
    Uncoil motorkw1.51.51.52.22.22.2

    Straightener head

    1. Adopt AirTAC cylinder, alloy cylinder body, hard oxidation, riveting air-tight solid aluminum, CNC precision machining, inner wall grinding smoothly, no stuck, high efficiency and high intensity operation, durable, suitable for all kinds of working conditions.

    2. Adopt worm gear screw lifter, the box body is made of HT200 material, the bearing is made of famous brand, with stronger impact bearing capacity and stronger durability.

    3. Adopt cast iron handwheel, surface electroplated, It is the most traditional handwheel.
