    Illuminated Black 16 Key 1.5mm Backlit Numeric Keypad

    Ask Lasest Price
    Brand Name : guangzhi
    Model Number : GZ-B001030
    Certification : FDA, SGS, ROHS, LFGB, REACH
    Price : To be quoted
    Payment Terms : T/T, Paypal
    Supply Ability : 100000pcs
    Delivery Time : 1-20 work days
    • Product Details
    • Company Profile

    Illuminated Black 16 Key 1.5mm Backlit Numeric Keypad

    Illuminated Black 16 Key 1.5mm Backlit Numeric Keypad


    LED illuminated keyboard product number: GZ-B001030


    Product size of numeric keypad: 100 * 100mm

    Password keyboard description:

    16-key numeric keypad adopts stretch button design and is equipped with 16 keys. The key stroke is 1.5mm, assembled from the outside to the inside, and the thickness is 28mm (including the bottom case); it adopts an all-stainless steel panel and is coated with a black protective film to make the appearance more beautiful;

    Application of light waterproof keyboard

    Designed for harsh environments, it has good waterproof, dustproof and anti-damage performance. The panel uses stainless steel black titanium plating process to make it more beautiful. The special waterproof design and protection level IP 67 make it suitable for public places or harsh environments Ideal choice in. Mainly suitable for special products such as self-service vending machines, banks, gas stations, outdoor self-service car wash machines, etc.;

    The performance of the access control numeric keypad:

    1. LED font light, environmental protection and energy saving, the service life exceeds 30,000 hours, and it is more convenient to operate at night.
    2. The keyboard adopts long-stroke convex keys, which has a good tactile visual experience. It is clearer to use in a dim environment, and can achieve user-free, fast and accurate data input without noise.
    3. Customize any button surface in multiple languages ​​to adapt to different countries and various custom styles.
    4. It has good waterproof, dustproof and vandalism performance, which is an ideal choice for public places or harsh environments.

    Current parameters of the mini metal numeric keyboard:

    1. Power supply voltage 0-24V DC

    2. Contact resistance 5 ohms (maximum)

    3. Interface: Matrix 8PIN 2.54mm, USB, PS2, R232, R485

    4. OS: All windows, Linux, Unix, Mac OSX

    Mechanical specifications of metal keyboard:

    Keys

    16 keys

    Button size

    14*14mm, 14*28mm

    haracter of the key's surfacelaser mark and a heavy painting

    Key stroke

    0.5mm

    Button life

    2 million times

    Button elasticity

    1.2N +/- 0.1N (contact strength)

    relative humidity20-95%RH

    Keyboard life

    > 5yer

    Working current

    DC + 5V / -5%

    Key switch technology

    rubber keys

    Interface technology

    1 * 8PIN and 1 * 2P (light)

    Operating system

    DOS / Windows95 / 98 / NT / ME / 2000/2003 / XP / Vista, Linux, Unix, Mac osx


    CAD drawing of 16-key numeric keypad:

    Pictures of the front and back of the metal keypad:




    FAQ
    Q1) What information should I provide to get a quotation? When can I get the quotation?
    Answer: We will send you a quotation within 24 hours after you provide the size drawing, quantity and special requirements, if there are samples that can be provided, it is the best.
    Q2) Are you in the factory?
    Answer: Yes! Shenzhen Guangzhi Technology is a professional manufacturer of metal keyboards with a history of more than ten years.
    Q3) Do you support custom keyboard language and layout?
    Answer: We support free language and layout customization!
    Q4) Can the surface and procedure of the product be customized according to my requirements?
    Answer: Yes. You only need to provide the requirements;

    Q5) What is your guarantee for the product?
    Answer:All our products have a one-year warranty from the date of shipment. But we are maintenance for life, but need to pay other costs.

    Q6): What is the delivery time?
    Answer:Bulk orders: 2-20 days, depending on the order quantity. Sample: 1 day when in stock, 20 days for custom design.
