LJSCLM CNC Intelligent Automatic High Speed Glass Cutting Line and
Horizontal Washer 1600
LJSCLM CNC Automatic Glass Cutting Machine glass cutting Line has
been comprehensively upgraded by means of introduction of European
leading technology, world newest tech and process to eliminate the
insufficient performances, incomplete functions and unstable
operation from domestic glass loader, moreover,through the precise
racks, slide-rails, servo motors and pneumatic elements, it
achieves the long-term stable accuracy and fast running with the
newest American Galil control system, it features even faster
operation, higher safety, higher efficiency, more stability and
better accuracy: with the photoelectric positioning, it facilitates
the simple and precise operation and prominent labor saving
LJSCLM CNC Glass Cutting Machine
Technical data
| Max. glass cutting size | 2800*4200mm |
| Glass thickness | 2-255mm |
| Cutting speed(m/min) | 0-200 |
| Accurcy(mm/m) | ≤±0.20 |
| Breaking bar(pcs) | 1+2 |
| Total power | 3P 380V 50Hz |
| Dimension | Dimensions :14200x3750x900 ±20mm |
| Total weight | 3700KG |
LJSCLM CNC Intelligent Automatic High Speed Glass Cutting Line is
ready for installation
LJSCLM CNC Intelligent Automatic High Speed Glass Cutting Line is
ready for working in our customer's workshop
Horizontal glass washing Machine(Model:1600)
Glass Horizontal Washer to wash 3-12mm and 35mm-thinner glass with the horizontal structure, it is stable to transmit;stable
performance with DELIXI contactor, push-button switches and pilot light.It
adopts frequency stepless speed and is easy to operate as the
button is concentrated on the operation table, the height of
washing tank can be changed to meet the requirement of any glass
thickness. Three groups of brushes assure the washing quality while
two pairs of air knives assure the drying. Inspecting light is
equipped to examine the glass quality
1. The machine is use for flat glass washing & drying.
2. Machine consist of loading part, washing part, drying part &
unloading part.
3. Adopt chain type transmission.
4. Machine with 4 pairs brushes, 3 pairs sponge rollers and one
water tank.
Product Detail
| Product name | Window Flat Glass Cleaning Horizontal Glass Washing Machine |
| Usage | Glass Washing and Drying |
| Water tank | One or two according to your requirment |
| Color | Customers' Request |
| Voltage | 380V(Can customize it according to your voltage) |
| Application range | Glass Deep processing for double glass,tempered glass etc. |
| Seaport | Qingdao Port |
| Max.Glass Size | 1600*2500 |
| Glass thickness | 3-12mm |
| Operation | Easy Opearation |
| Product Keywords | glass washing machine for tempered glass,glass washing line,glass
washer in edging production line for tempered glass |
• Wash online and offline low-e glass, automatically recognizes
Low-e film(option)
• Washing part adopts the design of upper and lower layered
structure
• Adopt variable frequency fan, energy efficient, good cleaning
effect
• Using intelligent intermittent energy-saving working methods
• Water tank automatic temperature control,
• 304 stainless steel materials(option)
Horizontal Hot Press Machine(Model:YRB1600A)
Function and feature
1. It adopts two rubber rollers and frequency stepless speed so the
transmission speed can be changed if necessary.
2.Temperature controlling device (8 heating pipes with 2kw power),
Is used to keep the best temperature to assure the quality of the
insulating glass.
3.The rollers in the hot stove are made of materials good in
lubrication and heatproof.
Jinan Lijiang Automation Equipment Co., Ltd. is located in the
beautiful spring city------Jinan. It is an enterprise which
integrated glass processing equipment research and development,
sales and service into a whole world . As it is close to
Beijing-Shanghai high-speed rail, the transportation is very
convenient.
The company is committed to building high-end insulating glass
machinery and equipment by learning from famous experts,
establishing the research and development centers, cooperating with
domestic and foreign well-known enterprises, importing advanced
technology and so on. Now, our friendly partners include North
Glass, Xin Fuxing, Yaohua, Dalian Huaying, Beijing Guanhua,
Shanghai Hao Jing, Sichuan Li Hehua and other well-known
enterprises. Since the establishment of the company, our products
have been exported to Europe, America, South America, the Middle
East, Southeast Asia, India, nearly 30 countries and regions. At
the same time, our company worked with the well-known domestic
research institutes, such as the North China Industrial Group,
Shandong University and others, to constantly improve the level of
technical research. So far, we have independently produced the
vertical automatic IG production line with filling gas on line, the
vertical IG sealing robot, the automatic spacer bending machine,
the automatic desiccant filling machine and the new fully automatic
butyl extruder machine, its technology and quality have reached the
highest leading level in China.
With the rapid development of insulating glass industry, LIJIANG is
looking forward to working with you for win-win situation and
jointly creating a new world.
