    High Speed Fluid Level Meter Radar Level Transmitter Small Antenna Size Easy To Install

    Ask Lasest Price
    Brand Name : KACISE
    Model Number : KLD-2604
    Certification : CE
    Price :
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram, Paypal
    Supply Ability : 10000pcs/month
    Delivery Time : 5-8 working days
    • Product Details
    • Company Profile

    High Speed Fluid Level Meter Radar Level Transmitter Small Antenna Size Easy To Install

    Kacise solid material strong dust easy to crystallize condensation occasion appliation 26G radar level sensor

    Principle


    Radar level transmitter antenna microwave pulse is narrow, the downward transmission antenna. Microwave exposure to the medium surface is reflected back again by the antenna system receives, sends the signal to the electronic circuit automatically converted into level signals (because the microwave propagation speed, electromagnetic wave to reach the target and the reflected back to the receiver this time is almost instantaneous).


    • The characteristics of 26G radar level meter:

    1) Small antenna size, easy to install; Non-contact radar, no wear, no pollution.

    2) Almost no corrosion, bubble effect; almost not affected by water vapor in the atmosphere, the temperature and pressure changes.

    3) Serious dust environment on the high level meter work has little effect.

    4) A shorter wavelength, the reflection of solid surface inclination is better.

    5) Beam angle is small, the energy is concentrated, can enhance the ability of echo and to avoid interference.

    6) The measuring range is smaller, for a measurement will yield good results.

    7) High signal-to-noise ratio, the level fluctuation state can obtain better performance.

    8) High frequency, measurement of solid and low dielectric constant of the best choice.

    Parameters


    Suitable for MediumPowder, granule, bulk solid
    ApplicationLime powder, cement, coal ash, coal and ore etc. in silo
    Measuring Range50m for powder, 70m for granule and block
    Process ConnectionFlange, Min. flange is DN250
    Medium Temperature-40 ~ 250
    Process Pressure-0.1 ~ 0.1MPa
    Accuracy±20~50mm
    Protection GradeIP67
    Frequency Range26GHz
    Explosion-proof GradeExia IICT6 Gb
    The signal Output4 ~ 20mA/HART(2 wire/4wire),RS485/Modbus is optional

    The Electrical Connection

    (4~20)mA/HART (Two wire system) The power supply and the output current signal sharing a two core shield cable. The supply voltage range see technical data. For intrinsically safe type must be a safety barrier between the power supply and the instrument.
    (4~20)mA/HART(Four wire system) Separate power supply and the current signal, respectively using a two-core shielded cable. The supply voltage range see technical data.
    RS485 / Modbus Power supply and Modbus signal line separate drespectively using a two-core shielded cable, the power supply voltage range see technical data.

    Product Overview

    This series of radar level meter adopted 26G high frequency radar sensor, the maximum measurement range can reach up to 80 meters. Antenna is optimized further processing, the new fast microprocessors have higher speed and efficiency can be done signal analysis, the instrumentation can be used for reactor, solid silo and very complex measurement environment.
