    CK6140 CNC Lathe Machine CK Series , Heavy Duty Mini CNC Horizontal Lathe Machine

    Ask Lasest Price
    Model Number : CK6150/6160
    Payment Terms : T/T, Western Union, MoneyGram
    Delivery Time : 15-30 days after received payment
    • Product Details
    • Company Profile

    CK6140 CNC Lathe Machine CK Series , Heavy Duty Mini CNC Horizontal Lathe Machine


    CK6140 Cnc Lathe Machine CK Series Heavy Duty Mini CNC horizontal Lathe Machine


    Metal lathe machine is widely used in electrical equipment, Instrument apparatus industry, Cars, Motorcycle parts, Fastener bearing, Photographic equipment, movie mechanical, hardware various clocks and watches,The glasses, Stationery, electric machinery, Valves, Gas pipe fittings and other high precision machining and manufacturing of complex parts, Is a hardware machinery processing industry the most ideal efficient equipment. Is a hardware machinery processing industry the most ideal efficient equipment.


    SpecificationsUnitCK6136CK6140CK6150
    Max.swing over bedmm360400500
    Max.swing over cross slidemm150180280
    Distance between centersmm1000/15001000/15001000/1500
    X/Z axis travelmmX:220 Z:1050/1600X:220 Z:1050/1600X:220 Z:1050/1600
    Spindle transmission typeMechanical 2 gear transmission ,in gear variable speedMechanical 2 gear transmission ,in gear variable speedMechanical 2 gear transmission ,in gear variable speed
    Spindle speed steepvariablevariablevariable
    Spindle speedrpmL:70~560,H:200~1600L:70~560,H:200~1600L:70~560,H:200~1600
    Spindle noseC6C6C6
    Thru-hole dia.of spindlemm525252
    Spindle taperMT6MT6MT6
    Spindle motorKW5.55.57.5
    Chuck sizemm200200250
    Ball screw dia.and pitchmm25X6/40X825X6/40X825X6/40X8
    X/Z axis feed motor torqueN.mX:6 Z:10X:6 Z:10X:6 Z:10
    X/Z axis feed motor powerKWX:1.5 Z:2.5X:1.5 Z:2.5X:1.5 Z:2.5
    X/Z axis fast moving speedmm/minX:6000 Z:8000X:6000 Z:8000X:6000 Z:8000
    X/Z axis Position accuracymm0.02/0.0250.02/0.0250.02/0.025
    X/Z axis repeatabilitymm0.01/0.0150.01/0.0150.01/0.015
    Processing accuracyIT6-IT7IT6-IT7IT6-IT7
    Workpiece surface roughnessRa1.6Ra1.6Ra1.6
    Tailstock sleeve dia.mm656575
    Tailstock sleeve travelmm140140140
    Tailstock sleeve taper#MT4MT4MT5
    Guide formSpindle mountain+flat railSpindle mountain+flat railSpindle mountain+flat rail
    Total power capacityKVA101010
    Machine dimension(L×W×H)mm2500/3000X1500X16502500/3000X1500X16502500/3000X1500X1650
    N.W.kg1500/20001800/23002000/2500

    a. High processing precision and stable processing quality;
    b. Multi-coordinate linkage can be performed to process parts with complex shapes;
    c. When the machining parts are changed, generally only the NC program needs to be changed, which can save production preparation time;
    d. The machine tool itself has high precision and rigidity, and can choose favorable processing amount and high productivity (usually 3~5 times of ordinary machine tools);
    e. The degree of automation of the machine tool is high, which can reduce the labor intensity;



    1. What is the payment Terms ?
    A : T/T ,30% initial payment when order ,70% balance payment before shipment
    When we receive the advance payment, we will start to make production.when the machine is ready , we will take pictures to you.after we got your balance payment. we will send the machine to you.

    2. What is your trade terms?
    A : FOB, CFR and CIF all acceptable.

    3.When is the delivery time?
    A: If the machine you will order is standard machine, we can ready the machine within 15days. if some special machines will be some longer. The ship time is about 30 days to Europe, America. If you are from Australia, or Asia, it will be shorter. You can place order according to delivery time and ship time.we will give you the answer accordingly.

    4. What is your trade terms?
    A : FOB, CFR,CIF or others terms are all acceptable.

    5. What is your minimum order quantity and warranty?
    A: MOQ is one set, and warranty is one year.but we will offer lifetime service for machine.

    6. What is the package of the machines?
    A: The machines standard will be packed in plywood case.
