Automatic Parallel CNC Coil Winder Making Transformer Coil

Parallel CNC Wire Winder Automatic Coil Winding Machine Making Transformer Coil

Introduction of automatic coil winding machine ZPX600

Automatic coil winding machine ZPX600 is one kind of professional wire coil winders, which is mainly used to wind transformer coils and other similar products. With its big torque, the automatic coil winding machine can not only wind aluminium wire but also wind copper wire. Through control system based on PLC and the touch scree, the automatic coil winding machine can be operated easily. The automatic coil winding machine can wind different sizes and shapes of coil automatically after inputting corresponding parameters. The maximum winding width of the automatic coil winding machine is 600mm. The winding speed of the automatic coil winding machine is 200rpm and can be adjusted stepless. The automatic coil winding machine features easy operation, high automation, slow starting, high automation and so on.

Main features of automatic coil winding machine ZPX600

• slow starting
• smooth running
• strong pulling force
• high reliability
• high accuracy
• full function

Main parameters of automatic coil winding machine ZPX600

The typical stand specifications of automatic coil winding machine ZPX600 is as following, however, the coil winding machine can also be manufactured as requested.

Fig 1: Automatic coil winding machine ZPX600's front view

Fig 2: Automatic coil winding machine ZPX600's wire guide
