SS304 Customized Distiller Packed Metal Structured Packing for
Distillation Column
Metal Structured Packing Type
Metallic Structured Packings include perforated & corrugated
plate,corrugated plate gauze, pricked & corrugated plate,Corrugated
wire gauze and, annular corrugated plate.
Orifice corrugated packing is a structured packing assembled with
holes on the surface of metal sheet and large corrugations. It has
the characteristics of low resistance, uniform gas-liquid
distribution, high efficiency, large flux, and insignificant
amplification effect. pressure and pressurization operations.
Wire mesh corrugated packing is an important milestone in the
development of structured packing. This packing is formed by
arranging corrugated wire mesh sheets. The inclination angle of the
corrugated sheets is 30° or 50°. The directions of the adjacent two
corrugated sheets are opposite. When , the upper and lower
two-person trays are staggered and stacked at 90°. It has the
advantages of high efficiency, pressure drop and large flux. The
products are BX and CY type, which are often used in vacuum
distillation, atmospheric distillation and suction process of
difficult to separate and heat-sensitive materials.
Punctured corrugated packing is a structured packing formed by
rolling a slanted metal sheet to form small punctured holes with
high density and then pressing into corrugated sheets. Wire mesh
corrugated packing and other properties.
Metal Structured packing characteristics:
1. High number of theoretical plates, high flux and low pressure.
2. The number of theoretical plates increases with the decrease of
gas load, and there is no low load extreme.
3. Flexible operation.
4. The extension effect is not obvious.
5. It can satisfy the requirements of high precision, large scale
and high vacuum distillation of distillation equipment. Material:
stainless steel, brass, phosphor copper, low carbon steel, etc.
Use: hard separation system, thermal sensitive system, distillation
and separation of high purity products.
Metal Structured packing model:
| Model | Surface area (m²/m³) | Void fraction % | Hydraulic Diameter (mm) | Theoretical Plate(piece/m) | Pressure drop(Mpa/m) | Dry Packing Factor m-1 |
| 125Y | 125 | 98.5 | 18 | 1-1.2 | 1.5 | 1307.4 |
| 250Y | 250 | 97 | 15.8 | 2-3 | 1.5-2 | 583.8 |
| 350Y | 350 | 95 | 12 | 3.5-4 | 1.5 | 489.2 |
| 450Y | 450 | 93 | 9 | 3-4 | 1.8 | 393.2 |
| 500Y | 500 | 92 | 8 | 3-4 | 1.9 | 229.8
|
About Us:
Anping County Hardware Mesh Products Co., Ltd. is located in Anping
County, Hebei Province, known as the "Hometown of Chinese Wire
Mesh". The company is a dedicated manufacturer of wire mesh
demisters. The company has more than 90 sets of knitted mesh
equipment. The wire mesh demister is the main product of our
company. Most of our employees are operation, maintenance, and
installation personnel with practical experience, who can provide
customers with the required engineering consultation and
installation of tank filtration. solution.Nearly 20 years of
experience in the production of mist eliminator mats, knitted wire
mesh, and other packaging materials.
We have ISO9001 certification and a strict quality control system
in the QC department of the enterprise.
We claim that all mist eliminator pads our customers receive are
qualified and perform perfectly. We have different specifications.
The filtration fineness can reach 3μm~5μm. In addition to standard
and popular sizes, we can also customize specific applications
according to customer needs.
During the company's development, through continuous on-the-spot
inspections, personal exchanges and cooperation with customers, and
comprehensive discounts and technical support, we have won strong
customer support and praise.
The company's performance has maintained an annual output value
growth rate of 30-40. Our employees pursue the policy of
"enterprising, truth-seeking, rigorous and united", continue to
develop and innovate, take technology as the core, and
wholeheartedly provide you with cost-effective products,
high-quality engineering design, and services.
Welcome customer consultation and I sincerely look forward to
cooperating with you!
FAQ:
Q: If I want to know the price, what information should I give you?
A: Material, size, application/purpose, quantity, payment term FOB
or CIF, packaging term, etc.
Q: Is the size fixed?
A: No, except for table size. Can be customized according to
demand!
Q: Can I negotiate the price?
A: Yes, we will give discounts according to the quantity and type
of products you need.
Q: How long is the delivery time?
A: It usually takes 7-10 working days; it depends on the specific
quantity and type.
