Technical parameters
♦ Used for delayed switching of lights in the corridors, entrances,
stairways, halls or for delayed finish of fans (WC, bathrom, etc.).
♦ It is controlled by a button or by several buttons from more
places (connected in parallel), buttons can be equipped by glow
lamps (max. 20pcs of glow lamps).
♦ Output relay contact 10A/AC 1 with surge current up to 20A
enables switching of el.
bulbs and fluorescent lamps.
♦ Operating system switch:
- AUTO - normal function according to set time.
- OFF - permanently OFF (e.g. when changing bulbs).
- ON - permanently ON (e.g. while cleaning, servicing).
♦ Time range: 0.5-10min.
♦ Time setting by potentiometer.
♦ Supply voltage: AC 230V.
♦ Protection against button blocking (e.g. a match inserted in a
button).
♦ 1-MODULE, DIN rail mounting.
