    Backlight Stainless Steel Keypad 20 Buttons Metal Numeric Keypad

    Ask Lasest Price
    Brand Name : IKB-MKB
    Model Number : B123KP-20-BL-DWP
    Certification : CE, FCC, ROHS, IP65, IP68, ISO 9001-2015
    Price : To be quoted
    Payment Terms : Full payment in advance, Western Union, T/T, Paypal
    Supply Ability : 3000psc/month
    Delivery Time : ASAP Within 2-3 weeks upon payment confirmed
    • Product Details
    • Company Profile

    Backlight Stainless Steel Keypad 20 Buttons Metal Numeric Keypad

    Stainless Steel Backlight Key Pad 20 Buttons Metal Numeric Keypad


    DESCRIPTION: 20 keys compact format IP67 dynamic water proof and vandal proof Stainless Steel industrial keypad with industrial electronics controller shielded and protected via stainless steel housing, industrial metal dome PCB with gold-on-gold key switch technology with short stroke 0.45mm with excellent tactile feeling for stable and accurate data input, stainless steel key caps etched out via special professional way and filled

    with transparent epoxy for backlight out, with industrial backlight included(Red/blue/white/green optional),top stainless steel plate with welded studs and water-tigth gasket for easy mounting and tightening to enclosure or panel with top panel mounting solution.Which is good for outdoor application with direct rain and very harsh environments with humidity, much dynamic water, oil, dirt, salt mist etc.
    DIMENSIONS: 123.0mm x 237.0mm (front panel)
    ELECTRICAL DATA
    Supply Voltage: +5V DC +/-5%
    Current Rating: appr. 150mA
    EMC Standard: EN 55032:2015 EN 55035:2017
    Lifespan > 5 years
    Switch Contact Material: Gold-on-Gold key switch technology PCB.
    Interface: PS2, USB, RS232, RS485 available
    OS: All Windows, Linux, Unix, Mac OSX, Vxworks, Android, (U-cos--To be confirmed)
    MECHANICAL DATA
    Front plate: Super quality SUS304 brushed stainless steel
    Back plate: Super quality SUS304 stainless steel
    Actuator/Key: 20 keys, super quality SUS304 brushed stainless steel
    Key top style: protuberant rectangular keys, with laser engraved and etched legends and raised dots available.
    Key size: 14.0mm x 21.0mm for normal key, 14.0mm x 46.0mm for enter key.
    Switching material: Gold-on-Gold.
    Actuation Force: 4.0N+/-0.1N for key 14.0mm x 21.0mm (pressure point)
    Key Travel: 0.45mm.
    Key life: more than 1 million of operations
    Dimensions: 123.0mm x 237.0mm.
    G.W. 0.8kg.
    ENVIRONMENTAL ADAPTABILITY
    Operating temperature:-20oC to +60oC
    Storage temperature: -30oC to +70oC
    Operating RH: 30-90%
    Atmospheric pressure: 60-106Kpa.
    Saline mist: 96 hours, IEC 60512-6
    Damp heat test at + 40oC: 21 days, IEC 60512-6
    Dry heat test at + 85oC: 10 days, IEC 60512-6
    RELIABILITY
    ROHS Compliant, CE and FCC, ESD
    Protection Level: IP67 (front panel)
    Vandal resistant IK09
    Key Lifespan > 1 million actuations
    MTBF > 20000H
    MTTR < 30min
    APPLICATION
    This Keypad is mainly targeted for use for unsupervised or semi-supervised positions of varied access applications, internet terminals and information kiosks at universities, shopping malls, hotels, banks, airports, railway-stations and other public areas, ticket vending machines, gas stations, cash machines (ATMs/CDM), Internet public phones etc.
