    42hs48-1504a nema 17 stepper motor 4 wire bipolar or unipolar 1.8deg 40mm Medical machinery

    Ask Lasest Price
    Brand Name : JSS
    Model Number : 42HS48-1504A
    Certification : CE,ROHS,ISO
    Price : USD 5-7 pcs
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 10000 pcs month
    Delivery Time : 12 days
    • Product Details
    • Company Profile

    42hs48-1504a nema 17 stepper motor 4 wire bipolar or unipolar 1.8deg 40mm Medical machinery

    Medical machinery Nema 17 Stepper motor bipolar stepper motor hybrid stepper motor


    Changzhou Jinsanshi Mechatronics Co. Ltd. is located in Changzhou city, Jiangsu province, China. We are a comprehensive company which specializes in producing and researching motors and drivers. Our main products include hybrid step motor, and step driver, step servo motor and driver, integrated step servo motor, linear stepper motor, geared stepper motor, stepper motor with brake, brushless dc motor. And we are always researching and developing new products.


    our main products:

    hybrid stepper motor and drives

    Brushless DC motor and drives

    planetary gearbox

    AC servo motor

    Spindle motor

    Linear guide and its pairs

    Ball screw and its pairs


    General specifiation

    Step Angle1.8°
    Temperature Rise80℃ Max
    Ambient Temperature-20℃ Max∼+50℃
    Insulation Resistance100M ΩMin.,500VDC
    Dielectric Strength500VAC for 1 minute
    Shaft Radial Play0.02Max (450g-load)
    Shaft Axial Play0.08Max (450g-load)
    Max. Radial Force28N (20mm from the flange)
    Max. Asial Force10N

    Electrical Specification:

    Model NoStep Angle()Rated Voltage(V)Rated Current (A)Phase Resistance()Phase Inductance (mH)Holding Torque (Kg.cm)Detent Torque(g.cm Max)Rotor Inertia (g.cm)Motor Length (mm)Leads No.Motor Weight(Kg)
    42HS48-04041.8120.430454.5280684840.38
    42HS48-10041.84.514.5105280684840.38
    42HS48-13041.84.61.33.56.65.5280684840.38
    42HS48-15041.84.21.52.85.55.5280684840.38
    42HS48-16841.83.41.6823.85.2280684840.38
    42HS48-04061.8120.430283.2280684840.38
