Keysight Agilent N9917A FieldFox Handheld Microwave Analyzer 18 GHz
Description of Keysight Agilent N9917A
Keysight's FieldFox portable analyzers are equipped to handle your
toughest working environments during routine maintenance, in-depth
troubleshooting, and anything in between. Choose the Keysight
FieldFox configuration that best meets your needs.
Overview and Features of N9917A FieldFox Handheld Microwave
Analyzer
- Standard model includes cable and antenna analyzer.
- Expand capabilities with optional VNA, spectrum analyzer, built-in
power meter, vector voltmeter, and more.
- Save time by measuring DTF and TDR in the same sweep.
- Measure all four S-parameters simultaneously.
- Make accurate spectrum analyzer measurements (± 0.5 dB) without
warm-up.
- Calibrate easily with QuickCal.
- Use the industry's lightest all-in-one analyzer at only 3.0 kg (6.6
lb).
Applications
- S-Parameters
- Distance-To-Fault
- Cable Trimming
- Return Loss
- Insertion Loss/Gain
- Interference Analysis
- Power Measurements
Components
- Cables
- Antennas
- Amplifiers
- Filters
- 75 Ohm CATV Devices
Additional CAT/VNA Based Features
- QuickCal (Subset)
- Vector Voltmeter
- Mixed-Mode S-Parameters
- TDR Cable Measurements
Additional SA Based Features
- Built-In Power Meter
- Extended Range Transmission Analysis (ERTA)
System Features
- Built-In DC Source
- GPS Receiver - Internal and External
| Standard Attenuator Range | 30 dB |
|---|
| Standard Attenuator Step | 5 dB |
|---|
| Maximum Dynamic Range 3rd Order @1 GHz | n/a |
|---|
| DANL @1 GHz | -155 dBm |
|---|
| Maximum Analysis Bandwidth | n/a |
|---|
| Phase Noise @1 GHz (1 MHz offset) | -113 dBc/Hz |
|---|
| Phase Noise @1 GHz (10 kHz offset) | -111 dBc/Hz |
|---|
| Phase Noise @1 GHz (30 kHz offset) | -110 dBc/Hz |
|---|
| TOI @1 GHz (3rd Order Intercept) | +15 dBm |
|---|
| Applications Available | Yes |
|---|
| Frequency | 5 kHz to 18 GHz |
|---|
| Overall Amplitude Accuracy | ±0.5 dB |
|---|
| Bandwidth Options | 5 MHz |
|---|
| Frequency Options | 18 GHz |
|---|
| Performance Level | ?????? |
|---|
| Applications-Cellular | n/a |
|---|
| Applications-Digital Video | n/a |
|---|
List of Options
| 010 | Vector Network Analyzer Time Domain |
| 210 | Vector Network Analyzer Transmission/Reflection |
| 211 | Vector Network Analyzer Full 2-port S-parameters |
| 215 | TDR Cable Measurements |
