    ESP32-S3 Tft Lcd Module 480*270 HMI 4.3 Inch Tft Lcd Display Arduino LVGL

    Ask Lasest Price
    Model Number : ESP32-4827S043N
    Price : ¥108/PCS
    Payment Terms : L/C, T/T
    Supply Ability : 5000PCS/day
    Delivery Time : 28day
    • Product Details
    • Company Profile

    ESP32-S3 Tft Lcd Module 480*270 HMI 4.3 Inch Tft Lcd Display Arduino LVGL

    4.3 inch Without Touch 4.3" 480*270 ESP32-S3 HMI Arduino LVGL WIFI&Bluetooth Smart Display Screen RGB LCD TFT Module
    ESP32 development board-8M PSRAM 16M Flash, standard 4.3-inch TFT screen and Without touch or Resistor touch or Capacitive touch , support one-key automatic download, provide LVGL demo and arduino examples
    Product Usage
    • 1. Generic Low-power IoT Sensor Hub

    2. Generic Low-power IoT Data Loggers
    3. Cameras for Video Streaming
    4. Over-the-top (OTT) Devices
    5. USB Devices
    6. Speech Recognition
    7. Image Recognition
    8. Mesh Network
    9. Home Automation
    10. Smart Building
    11. Industrial Automation
    12. Smart Agriculture
    13. Audio Applications
    14. Health Care Applications
    15. Wi-Fi-enabled Toys
    16. Wearable Electronics
    17. Retail & Catering Applications

    model:ESP32-4827S043N

    Size:4.3 inch

    Resolution:480*272

    Touch mode:Resistive touch

    Viewing angle:TN

    Interface mode:16bit RGB

    Operating temperature:-20°-70°

    Weight:140g

    External dimensions:123.0*74.0mm

    Display size:95.04*53.86mm

    Operating voltage:5V

    Backlight parameters:6 in parallel and 2 in series

    Pin definition:type-c


    Introduction


    The ESP32 WiFi and Bluetooth chip is the latest generation of Espressif products. It has a dual-core 32-bit MCU, which integrates WiFi HT40 and Bluetooth/BLE 4.2 technology inside.

    ESP32-S3-wroom-1 has a significant performance improvement. It is equipped with a high-performance dual-core Tensilica LX7 MCU. One core handles high speed connection and the other for standalone application development. The dual-core MCU has a 240 MHz frequency and a computing power of 600 DMIPS.

    In addition, it supports Wi-Fi HT40, Classic Bluetooth/BLE 4.2, and more GPIO resources.


    Product description


    This LCD module uses ESP32-S3-WROOM-1 module as the main control, the main control is a dual-core MCU, integrated WI-FI and Bluetooth functions, the main frequency can reach 240MHz, 512KB SRAM, 384KB ROM, 8M PSRAM,Flash size is 16MB, The display resolution is 480*272 or 800*480, resistive touch or Capacitive touch. The module includes LCD display screen, backlight control circuit, touch screen control circuit . Reserve the TF card interface ,IO port interface, this module supports development in arduino IDE, ESP IDE, Micropython and Mixly.


    Features


    ●4.3-inch color screen, support 16 BIT RGB 65K color display, display rich colors·

    ●480X272 resolution

    ●The sample program has been programmed in the factory and can be plugged in

    ●With TF card slot for easy expansion storage

    ●Provide arduino library functions and sample programs to facilitate rapid secondary development

    ●Support one-click download program·

    ●Military-grade process standards, long-term stable work·
