Non-Ferrous Metal Flotation Separator With Easy Operation And
Maintenance:
Flotation machine is self-prime air&puple, tank is frontloaded,
good for bubble returning; It has double blades impeller,has good
mixing low consumption; horizontal placement,no need bubble pump;
Imepllers have slow rotation speed, Impeller cover has durable
life;The pump is double cycling in fixed form of up & down,which is
good for coarse ore to suspended.
Agitator of Non-Ferrous Metal Flotation Separator:
Each flotation cell has been designed with triple functions
including air-suction, pulp-suction and flotation separation
respectively, by which a self-circulation flotation process is
formed without the necessity for other auxiliary equipment.
Logical design of pulp circulation can reduce settling of grit to
the largest extent.
Equipped with self-controlling system, depth and surface of pulp
contained in each cell can be conveniently adjusted.
Impeller is composed of up and bottom impeller vanes, by which up
circulation and bottom circulation of pulp can be produced
separately.
Working principle of Non-Ferrous Metal Flotation Separator:
The impeller is rotated by V-belt of motor and produces negative
pressure by centrifugal function. Enough air is sucked to mix
slurry, and slurry mixes drug at the same time. Mineral sticks on
bubble completely and floats on the surface of slurry to form
mineralized bubble. Useful bubble is scraped out by adjusting
flashboard height and controlling liquid surface, One or more gas
chambers are installed in the bottom of the tub, on the cover of
the gas chamber are full of one-way valves. when the one-way valves
are open, the pressed air will be fed into the flotation cell.
Application of Non-Ferrous Metal Flotation Separator:
Non-Ferrous Metal Flotation Separator be used to separate
non-ferrous metal, ferrous metal, noble metal, non-metallic mine,
chemical material. It can be used in roughing, scavenging,
selection or reverse flotation. In the flotation process, after
being mixed with drug, some qualified mineral attaches on bubble,
floats on the surface of slurry and is scraped out, other mineral
still stays in the slurry, so the separating purpose is finished.
Flotation stages of Non-Ferrous Metal Flotation Separator:
Roughing: The first stage is called roughing, which produces a
rougher concentrate.
Cleaning: The rougher concentrate is normally subjected to further
stages of flotation to reject more of the undesirable minerals that
also reported to the froth, in a process known as cleaning.
Scavenging: The rougher flotation step is often followed by a
scavenger flotation step that is applied to the rougher tailings.
Technical Data of Flotation Separator:
| Model | Capacity | Power(kw) | Dimension(m) | Pipe connection(DN) |
| (m3/h) | Recycle pump | Air compressor | Skimming system | L/L1 | W/W1 | H/H1 | (a) Water inlet | (b) water outlet | (c) sludge outlet |
| HK-002 | 1~2 | 0.75 | 0.55 | 0.2 | 3.2/2.5 | 2.4/1.16 | 2.2/1.7 | 40 | 40 | 80 |
| HK-003 | 1~3 | 0.75 | 0.55 | 0.2 | 3.5/2.8 | 2.4/1.16 | 2.2/1.7 | 80 | 80 | 100 |
| HK-005 | 1~5 | 1.1 | 0.55 | 0.2 | 3.8/3.0 | 2.4/1.16 | 2.2/1.7 | 80 | 80 | 100 |
| HK-010 | 1~10 | 1.5 | 0.55 | 0.2 | 4.5/3.8 | 2.7/1.36 | 2.4/1.9 | 100 | 100 | 100 |
| HK-015 | 1~15 | 2.2 | 0.75 | 0.2 | 5.5/4.5 | 2.9/1.6 | 2.4/1.9 | 100 | 100 | 100 |
| HK-020 | 1~20 | 3 | 0.75 | 0.2 | 5.7/4.8 | 3.2/2.2 | 2.4/1.9 | 150 | 150 | 150 |
| HK-030 | 1~30 | 3 | 0.75 | 0.2 | 6.5/5.5 | 3.2/2.2 | 2.5/2.0 | 150 | 150 | 150 |
