DT Copper Cable Lug Connecting Terminals

Name: DT Copper Cable Lug Connecting Terminals
Brand: Jetacon
Price: 1 USD

Add to Cart

1.Material:copper
2.Plating:No
3.Certificates: ROHS
4.OEM/ODM
5.Various wire range

Dimension

DT Copper Cable Lug With Oil Plugging DT Copper Cable Lug With Oil Plugging DT Copper Cable Lug With Oil Plugging

Item No.	Cable spec (mm2)	Dimensions(mm)							Note
Item No.	Cable spec (mm2)	D	d	L	L1	W	φ	T	Note
DT10	10	9	5	68	28	16	8.5	3.8	(1)Can be produced according to customer's drawings
DT16	16	10	6.4	68	33	16	8.5	4
DT25	25	11	7.4	70	34	16	8.5	4
DT35	35	12	8.7	80	38	20	10.5	4
DT50	50	14	9.7	90	43	23	10.5	5
DT70	70	16	11.7	95	45	26	12.5	5
DT95	95	18	13.7	105	49	28	12.5	5
DT120	120	20	15.2	112	53	30	14.5	6
DT150	150	22	16.7	120	55	33	14.5	6
DT185	185	24	18.7	126	57	37	17	6.5
DT240	240	27	21	136	58	40	17	6.5
DT300	300	30	23	160	67	50	17	7
DT400	400	32	26	168	75	50	21	7.5
DT500	500	35	29	190	75	60	21	9.5
DT630	630	45	35	220	85	80	21	9.5
DT800	800	50	38	260	85	80	21	10

Oil plugged DT Type Copper Connecting Terminal Lugs(oil plugging), Oil plugged DT Type Copper Connecting Terminal Lugs
