    Watermelon Seed Kernels Walnut Sorting Machine Intelligent 8 Channels

    Ask Lasest Price
    Brand Name : Hons+
    Model Number : S8
    Certification : CE、SGS、ISO9001
    Price : Negotiable
    Payment Terms : L/C, T/T, T/T
    Supply Ability : 200sets/Year
    Delivery Time : 10-15 Work Days
    • Product Details
    • Company Profile

    Watermelon Seed Kernels Walnut Sorting Machine Intelligent 8 Channels

    Watermelon Seed Kernels Walnut Sorting Machine Intelligent 8 Channels


    Features

    Camera

    leading in the industry

    International well-known brand customized lens
    Import high-end 4096PIXEL CCD sensor
    High-speed of scanning
    The highest resolution comes to 0.02 mm²


    High-frequency Solenoid Valve

    leading in China

    High-quality high-frequency solenoid valve, with consistency of near zero error.

    Service life more than 1 billion times.
    Ultra high precision, leading in China


    Intelligent Image Processing Algorithm

    The combination of colors and shapes of

    intelligent algorithm
    Leading role in China.
    Precise professional sorting solutions


    Customized Lighting System

    import purchasing

    Advanced LED optical design system.
    Various light sources are available to suit different materials.
    Designated procurement of imported LED lamps,Higher stability, longer service life.
    LED lighting system with thermal dissipation.


    Data Transmission System

    high-speed and stable

    The COAX interface:
    High anti-jamming, high transmission speed, high stability


    Chip

    innovative ultra high-speed processing

    Based on SOC platform architecture;
    Compared to DSP platform, the CPU improves 5 times, output processing improves 4 times, realizing the stability ,reliability and high-speed mass data processing.


    Crawler Transmission:transmission structure
    The crawler-type transmission structure shows good performance in color sorting, and the stable material transmission can effectively improve the ratio of color separation mass and the net selection rate, meanwhile reducing the crushing rate of material in the course of color sorting.


    Schematic


    Product Parameter

    Nuts Color Sorter Models
    Model6SXZ-686SXZ-1266SXZ-1896SXZ-2526SXZ-3156SXZ-378
    Output(t/h)0.8-2.01.2-2.51.5-3.03.0-6.04.0-7.05.0-8.0
    Carryover Rate(Bad:Good)>12.5:1>12.5:1>12.5:1>12.5:1>12.5:1>12.5:1
    Sorting Accuracy(%)≥99.9≥99.9≥99.9≥99.9≥99.9≥99.9
    Voltage (v/Hz)220V 50HZ220V 50HZ220V 50HZ220V 50HZ220V 50HZ220V 50HZ
    Power Supply(Kw)≤1.5≤2.0≤2.4≤2.6≤3.0≤3.6
    Pressure(Mpa)0.4-0.60.5-0.70.6-0.80.6-0.80.6-0.80.6-0.8
    Weight(Kg)350500800100012501400
    Diamension(mm)910*1620*15501220*1620*15501628*1595*20401870*1595*20402210*1595*20402528*1595*2040

    Sorting example

    Watermelon Seeds Raw Material


    Watermelon Seeds Accept


    Watermelon Seeds Rejection


    Packaging & shipping

    Delivery Detail: Shipped in 15 days after payment

    Packaging: Plywood case


    Why choose Hons+?

    1. Over 11 years experiences focus on color sorter. The biggest sorter machine factory in China. We have the strength give better service and price to you.

    2. Overseas Service Station: We have service station, cooperate reseller more than 40 countries. Wesort can meet your requirements on testing, installation and after sales service.

    3. OEM/ODM is Supported: We have a strong R&G team(5 famous doctor engineers are included ). We can research and development suitable color sorter for you.

    4. Quality Process Assurance: We pass CE, RoHS and ISO quality management system, each process of production are under strictly standard.

    5. Shipping Guarantee: We have professional packaging operations team, independent export qualification to ensure product safety and stability to reach customers in the hands.

    6. After-sales Service Guarantee: We provide one year warranty and lifetime maintenance. Free home repair during the warranty period (except for human factors or irresistible natural phenomena caused by failure or damage)

    7. Sales team: Our professional sales team is fluent in English, Russian, Chinese , Spanish and Japanese. Can communicate better with customers.
