XWW-50KN Tensile Testing Machine Supplier/Tensile Testing Machine
Price
Description:
XWW series computerized electronic tensile testing machine price
are designed and
manufacture according to ASTM, ISO, DIN, GB and other international
standards.
Applicable for wide range of material for tension, compression,
bending, shearing and low cycle test. Suitable for metal, rubber,
plastic, spring, textile, and components testing. It is widely used
in the corresponding industries, research and development, test
institutes and training centers etc.
Main technical parameter of Tensile Testing Machine Supplier/Tensile Testing Machine Price:
| Model | XWW-50KN |
| Type | Double-arm |
| Max. Load | 50KN |
| Unit Switchover | Tone,Kg,g,Kn,Lb; mm,cm,inch |
| Accuracy Grade | 0.5% |
| Deformation-measuring Range | 2%~100%FS |
| Deformation-measuring Accuracy | 1% |
| Crossbeam Displacement Resolution | 0.001mm |
| Crossbeam Speed Range | 0.01~500mm/min |
| Displacement Speed Accuracy | ≤ 0.5% |
| Tensile Space | 700mm |
| Compression Space | 900mm (or according to order) |
| Effective test width | 480mm |
| Clamps | Wedge Grip,Compressing Attachment,Bend accessorises |
| PC System | Equiped with brand computer |
| Flat-specimen thickness | 0~20mm |
| Diameter for Round-specimen | 0~16mm |
| Power Supply | AC220V |
| Standards | ISO 7500-1 ISO 572 ISO 5893 ASTMD638695790 |
| Weight | 550KG/750KG |
Introduction of the UTM software:
Universal Testing Machine Software (more than the following)
- This software is of powerful function, including programs of
tensile, compressing, bending, sheering, peeling tests on metallic,
non-metallic, and other various materials.
- Based on Windows, simple operation and easy to learn.
- Languages switch between Simplified Chinese, traditional Chinese
and English.
- Ten user accounts and passwords can be created.
- It has the protection function of overloading: overloading value
can be set by user.
- The units of force or displacement can be switched easily. The
changes in stress and strain are displayed real time.
- Curves, like Load-displacement, load-time, displacement-time,
stress-strain, load-tensile length, etc. can be switched between
each other at any time.
- Force value dual-correction system: auto set and zero, auto
identification and import of correction data.
- It is suitable for many testing standards, such as ISO, JIS, ASTM,
DIN, GB etc.
- Compare among the test curves in the same group though piling them
up.
Auto zero set. Max force, upper-yield strength, lower-yield
strength, anti-tensile intensity anti-compression strength,
elasticity modulus, percentage of elongation, etc. are calculated
automatically.
Beijing Jinshengxin Testing Machine co.,Ltd,covering 20000 square
meters,is located in Jinhaihu Town of Beijing.Since founded in
1985,our company has been devoted to the research,development and
manufacture of testing machines for metallic and non-metallic
materials, especially building materials. We have kept a close
cooperation bond with many colleges and research institutes for
technical exchange.
Through these years’ efforts, our company has gained rapid
development because of outstanding talents and advanced science &
technology. Now it has become one of the best companies in the area
of testing instruments. All of our products have passed the
evaluation of CMC and ISO9001. The brand of our products is
“Jinhaihu”. Our main products are universal tensile testing
machines, impact testing machines, melt flow rate indexers, heat
distoration temperature-Vicat softening point testers, liquid
analyzers, prototype machines, pipe testers, etc. For the reliable
quality and high precision, our products are very popular in China
and abroad.
If you want to buy testing machines, our products are your first
choice!
Looking forward to cooperating with you!
