SMX 12000 Lumen 3LCD Laser Large Venue Laser Projector WUXGA for 3D
Mapping
Embark on a journey of creativity and innovation with our
groundbreaking SMX MX-12000U 12000 Lumen High Brightness Laser
Projector, meticulously engineered to redefine 3D mapping
experiences with stunning brightness and exceptional image clarity.
Equipped with WUXGA resolution, this projector opens up a world of
possibilities for a captivating and immersive 3D mapping display.
Key Features
Impressive Brightness:
Boasting 12,000 lumens of brightness, this projector delivers vivid
and clear images in any lighting conditions, ensuring exceptional
visibility in large venues and bright environments.
Enhanced Color Accuracy:
Experience true-to-life colors and stunning color reproduction with
advanced color calibration technology, bringing your visuals to
life with exceptional accuracy and vibrancy.
High-Resolution Projection:
Enjoy crystal-clear images with high-definition resolution,
capturing every detail precisely for an immersive viewing
experience that leaves a lasting impression.
Versatile Connectivity Options:
Seamlessly connect to various devices with multiple input ports,
enabling easy switching between sources for a smooth and
hassle-free user experience.
Flexible Installation Options:
Designed for versatility, this projector offers compatibility with
different lenses and mounting options, allowing you to customize
the setup to meet your specific requirements and venue constraints.
Specification
| Model No. | MX-X12000U |
| Brightness |
| | Brightness
( Ansi Lumens ) | 12000lumen |
| Light source | Laser |
| Overall Spec |
| Panel | Display Panel | 3x0.76" |
| Display Technology | Liquid Crystal Display |
| Native Resolution | WUXGA (1920 x 1200) |
Light source
Lifetime | Normal mode | 20000hrs |
| ECO mode | 20000hrs |
| Projection Lens | Len Type | Zoom Lens |
| Zoom/Focus | Manual(Standard Len) |
| Throw Ratio(16:10) | 1.46-2.95 |
| F#(Wide-Tele) | 1.7~2.37 |
| f(mm) | 24.4-48.6 |
| Zoom Ratio | 2 |
| Weight | Approx 0.8kg |
| Lens Shift V | +50%,-10% |
| Lens Shift H | ±20% |
| CR | Contrast Ratio(Min) | 3,000,000:1 |
| Noise | Noise(dB) | Normal(90%): 35dB
ECO1(75% ): 32dB
ECO2(45% ): 32dB |
| AR | Aspect Ratio | Native:16:10
Compatible: 4:3/16:9/normal |
| Terminal(I/O port) |
| Input | VGA | *1 |
| HDMI 1.4(IN) | *2 |
| USB-A | *1 (5V/1.5A) |
| USB-B | *1 (Display) |
| RJ45 | *1 (Display) |
| DVI-D | *1 |
| HD BaseT | *1 |
| HD-SDI(3G-SDI) | Optional |
Audio in
(mini jack,3.5mm) | *1 (VGA/DVI-D share) |
| Output | VGA | *1 |
| HDMI 1.4(OUT) | *1 |
Audio out
(mini-jack,3.5mm) | *1 |
| Control | RS232 | *1 |
| RJ45 | *1 (Control) |
| USB-B | *1 (For upgrade) |
| Wired Remote(IN) | *1 |
| Wired Remote(OUT) | *1 |
| Other Functions |
| Keystone | Keystone Correction | V: ±30°
H: ±30°
Pincushion/Barrel Correction
6 Corner Geometry correction
Grid ImageTune correction |
| OSD | Languages | 26 languages: English, German, French, Italian, Spanish, Polish,
Swedish, Dutch, Portuguese, Japanese, Simplified Chinese,
Traditional Chinese, Korean, Russian, Arabic, Turkish, Finnish,
Norwegian, Danish, Indonesian, Hungarian, Czech, Kazak, Vietnamese,
Thai, Farsi |
| LAN Control | LAN Control-RoomView
(Crestron) | Yes |
| LAN Control-AMX Discovery | Yes |
| LAN Control-PJ Link | Yes |
| Display Resolution | Computer Signal Input | VGA, SVGA, XGA, SXGA,WXGA,UXGA,WUXGA,4K@30Hz |
| Others | 360° projection | 360° Omni bearing installation |
| Edge Blending | Yes |
| Dimension&Weight |
| | MAX Dimensions
(WxHxD mm) | 600*218*503 |
| Net. Weight (KG) | ~25kg |
| Accessory |
| | Manual Languages | Chinese, English |
| Standard Accessories | Power cord(3m,Black), Remote control |
