Full Automatic Intelligent Line Marking Machine Shoe Material Shoe
Upper Visual Marking Machine
System for marking guide lines on leathers automatically and no
longer modularly through cardboard.
• Thanks to its innovative technology, it guarantees speed and high
levels of accuracy on different materials and patterns.
• Increased productivity, thanks to the dual movement axis with 8
cartridges (4+4)
• The work performed by the machine is equivalent to more than 6
employees working at the same time. •
The machine can perform different types of lines.
Applicable Material
Fabric, Rubber, Plastic, Genuine Leather, Artificial Leather
Print Efficiency
3000-5000PCS Per Hours
Adapted Workers/Set
1-2 People
Control Mode
CNC Vision Recognition
Identify File Format
Plt Dxf Ai
Transport Package
Wooden Carton
Production Capacity
3000sets
Features and advantages:
Camera visual recognition, intelligent positioning, one machine can
replace 5-10 people
Supports computer mapping and industrial camera visual positioning,
easy to operate, easy to learn.The line drawing pass rate is ≥99%,
and the line drawing accuracy reaches 0.02mm.
High-definition visual positioning, line drawing accuracy up to
0.02mm, optional automatic loading and unloading
It saves not only labor, but also 50% of ink and stencils.
Uniform high-speed jetting can save 50% of ink, saving the cost and
time of making stencils.
The automatic line drawing machine is flexible and versatile,
allowing line drawing on materials to be unrestricted
Not limited by materials, multiple styles, different cutting pieces
can achieve simultaneous line drawing
Recognize the shape and direction of the material , accurately
locate and draw the line automatically , and can recognize more
than 20 different pieces at the same time for meeting the user's
line drawing work.
Adopt customized servo motion module, fast speed, high precision
and low failure rate. Controlled by software activation,
auto-location, and material movement system of servo motor
Separately .
Application:
The shoe upper cloth line drawing machine is widely used in the
production and manufacturing of various types of shoes, including
sports shoes, leather shoes, casual shoes, etc. It can provide
efficient and precise marking solutions for shoe factories and
improve product quality and production efficiency.
After Sales Service
1. 12 months warranty for the whole machine. Technology support all
life time.
2. We will supply the machine with training video and user's manual
in English for installing, operation, maintenance and
trouble-shooting, and shall give technical guide by e-mail,
telephone, video online and so on, when you meet some problems of
installation, using or adjusting.
3. You can come to our factory for training. We will offer
professional guide. Direct and effective face-to-face training.
Here we have assembled equipments all sorts of tools and testing
facility,we will also provide accomadation during training period.
4. We can provide door to door service if needed.
Packaging & Shipping
FAQ
1.Is there any technical help after we receive Automatic shoe upper
marking line Machine?
Yes, we have perfect after-sale service team to supply technical
support on our customers. Our technical can assist you to install
machine and give you free training after you receive machine.
2. What value can this intelligent shoe line marking machine bring
to me?
This system is suitable for production line, easy to move, easy to
be integrated with other systems.Saving time and labour.
3. What's the mainly applications for the automatic shoe upper line
drawing machine?
Genuine Leather, Synthetic leather, suede, mesh, mid-sole, cloth,
canvas and other materials.
4.If there is some problems about shoe line drawing parts during
warranty period, will your company repair or replace for me?
Yes, we will. Please send the main part back to our company,we will
repair and send back them to you for free within warranty time. If
the problem part can not be repaired well ,we will send new one to
you within warranty time for free.
