ESD Vinyl Flooring Static Dissipative Floor Tiles| ESD and Antistatic Solution

Description of Conductive Floor Tiles:

Our static dissipative tile is a complete flooring solution designed to control static in static sensitive working areas.
The system comprised of tile, conductive adhesive, copper grounding strips works together to dissipate electrostatic charges, protecting people and preventing damage to expensive equipment.

Dissipates static to increase safety and prevent damage to expensive equipment
Provides a continuous static dissipative surface throughout the space – tile-to-tile connectivity

Size Spec:
Sheet size: 600mm*600mm/900mm*900mm
Roll size: 2m*20m/Roll

Thickness: 2.0mm/3.0mm (2.5mm customized)

PVC flooring features two main characteristics: stain resistance and easy cleaning.

Stain resistance is achieved through seamless interlocking and PUR surface treatment.
Various stains on PVC flooring do not penetrate the floor, preventing dirt residue and odors.

Item	Standard	Index
Size	EN426	600*600mm
Size	EN426	900*900mm
Thickness	EN428	2.0, 2.5, 3.0mm
Weight	EN430	2.0mm, 3.8kgs/m³
		2.5mm, 4.8/kgs/m³
		3.0mm, 5.8/kgs/m³
Surface Rresistance	DIN51953	10⁴-10⁶ Ω Conductive
Surface Rresistance	ASTMF-1550 or NFPA99	10⁶-10⁹ Ω Dissipative
Decay Time	SJ/T10694-2006(VI<100V)	Equal 0.4S
Charge Voltage	SJ/T10694-2006(VI<100V)	Equal 70
Fire Resistance	DIN 4102	B1
Combustion Properties	SJ/T11236-2001(<10s,FV-0)	Equal 0.35s Ifv-0
Amount of anti-wear	SJ/T11236-2001(less than 0.02g/cm³, 110r)	Equal 0.014
Anti-wear Properties	EN660pt₂	Ten-T < 2.0 mm³
Wheel Pressure	EN425	No influence
Residual Concavity	EN433, DIN51955	0.03mm(2.0mm)
		0.035mm(2.5mm)
		0.04mm(3mm)
Dimensional stability	EN434	Less than 0.1%
Color fastness	IDO105BO2	At least 6
Resistance to chenmicals	DIN423,DIN51958	offers excellent resistance ask for special sheet
