    DIN Type 2.0mm Pitch Pin Header Connector Straight 2 - 40 Pin Single Row Connector

    Ask Lasest Price
    Brand Name : HONSHI
    Model Number : 1420-11XXSXXXXXXNX01
    Supply Ability : 1000000 Box/Boxes per Week
    Price : $0.02 - $0.05/pieces
    Certification : ROHS/SGS/UL
    Payment Terms : T/T,Paypal
    Delivery Time : 10-15 Day
    • Product Details
    • Company Profile

    DIN Type 2.0mm Pitch Pin Header Connector Straight 2 - 40 Pin Single Row Connector

    2.0mm Pitch Pin Header Connector Single Row Straight 2 Thru 40 Pin Connector


    Product NamePin Header Connector
    Pitch0.8/1.0/1.27/1.27X2.54/2.0/2.54/3.96/5.08mm
    Positions2P-100P
    Current Rating1A/2A/3A/5A/7A
    Contact Resistance20mΩ Max
    Withstand Voltage500V /1000V AC/DC
    Insulation Resistance1000mΩ Min
    Operation Temperature40 to +105
    Contact MaterialBrass/Phosphor bronze
    Contact PlatingAu Or Sn over Ni
    Insulator MaterialPBT/PA6T/PA9T/LCP ( UL94V-0 )


    2.54mm DIN 41612 Connector 2 Row 64Pin Right Angle dip Male Phosphor Bronze 1 Drawing:1420-11XXSXXXXXXNX01.pdf


    Item name: Pin Header Connector
    1. The product precision and reliable performance.
    2. 0.8mm/1.0mm/1.27mm/2.0mm/2.54mm/3.96mm/5.08mm pitch pin header are featured products in our company.
    3.material: its material is brass wire, phosphor copper wire, pure copper wire, the surface of Gold plating, nickel plating.
    4. Pin header is called universal connector. Based on different designs for PCB,they choose different pitch connectors to meet.

    Service idea:


    1. Committed to providing customers with customized, small batch, multi variety, one-stop services.

    2. Quick response and effective communication, refined service timely delivery.

    3. Strict implementation of the ISO 9001 and ERP system, the supply of materials strictly in accordance with the quality and standard production control.

    4. Free designsupporting samples, the quality is safe and reliable, the price is competitive.


    Management Concept
    Responsibility Innovation Integrity Win-Win;
    Team Culture
    Thanksgiving Valute Respects Team efforts;
    Service Purpose
    Quality fisrt Customer Satisfaction Professinal Improving;
    Sustainable Manner
    HONSHI grow in a sustainable manner,to support our valued customers with flexibly customized interconnect solutions.
