300m Water Detection Machine Underground Water Detector Geophysical
Water Survey
Product Description:
The 300m underground water detector is our latest innovation,
utilizing multiple patented technologies. Lightweight and easy to
carry, the machine requires only a 10-meter measuring line,
allowing a single operator to complete the setup, thereby saving
manpower. It has a full touchscreen, simple controls, and an
external high-capacity memory card. With a one-button real-time
mapping function, the water detector can identify high-resistance
zones (faults) and low-resistance areas (such as water bodies or
mineral deposits), displaying geological anomalies instantly at the
measurement site.
Equipped with advanced built-in computing functions, the water
detector can automatically generate curve graphs and profile maps
at the touch of a button. This visual data helps users clearly
understand the subsurface structure, enabling quick identification
of ore bodies, caves, and aquifers. Additionally, the device has
high measurement accuracy, anti-interference capabilities, and a
rechargeable battery with up to 12 hours of standby, storing data
for up to 999 measuring lines and points per line, all without the
need for external data output.
Features:
1. High Speed and High Efficiency
The water detector can complete over 8,000 meters of profile
measurement in a single day, enabling the detection of geological
anomalies at varying depths. This increases prospecting speed and
efficiency by approximately 10 times compared to traditional
resistivity methods.
2. Easy to Carry
By utilizing low-frequency signals from the Earth's natural
electric field as the signal source, the system eliminates the need
for heavy power supplies. The entire set weighs less than 2kg,
making it highly portable and easy to transport.
3. Simple Operation
Training takes just 30 minutes for individuals without prospecting
experience to begin using the equipment effectively.
4. Good Accuracy and High Precision
With a measurement resolution of up to 0.001mV, the machine
delivers high stability and produces anomaly curves that match the
results of traditional electrical equipment during numerous field
surveys.
5. Anti-Interference Capability
Equipped with advanced anti-jamming technology and multiple
anti-interference designs, the water detector provides clear
anomaly curve results, even in weak signal areas, cities with high
electrical interference, or locations with external disturbances.
6. Mapping with One Button
The detector has an automatic mapping function; with just one press
of a button, it creates the map. After measurement, you can easily
pinpoint the drill well location.
7. Four Language Options
The device supports four languages: Chinese, English, French, and
Arabic, ensuring accessibility for a global user base.
Technical Parameters:
| Detect depth | Accuracy | channel | frequency | LCD |
| 200m | 0.001mv | 4 | Single,Triple 33 Frequency | Industrial 7-inch HD touch screen |
| 300m | 0.001mV | 6 | Single ,triple,40 frequency | Industrial 7-inch HD touch screen |
| 600m | 0.001mV | 8 | Single,triple ,56 frequency | Industrial 7-inch HD touch screen |
Applications:
The 300m single-channel water finder is used to determine the
location, depth, water yield and other related information of
groundwater to guide well drilling and water extraction operations
and improve the success rate of well drilling. It is widely used in
detailed investigation and survey of hydrogeology.
