    Carbon Steel Vibrating Screen Machine Tumbler Sieve For Blast Furnace Pellets

    Carbon Steel Vibrating Screen Machine Tumbler Sieve For Blast Furnace Pellets


    Introduction of Large Capacity Tumbler Screening Machine for Blast Furnace Pellets:

    Large Capacity Tumbler Screening Machine for Blast Furnace Pellets is an efficient screening machine which is designed to meet the high-density and large output sieving of the manufacturers. It uses a operating principle of slow acceleration and a longer residence time on the mesh surface area, the action is extremely gentle on the product being processed and is more suited to handle fragile material.


    Advantages of Large Capacity Tumbler Screening Machine for Blast Furnace Pellets:

    1. Up to 100% availability in 24h operation with few maintenance requirements

    2. Low acceleration, long service life of all parts, no product destruction

    3. 100% statically and dynamically balanced for vibration free installation in steel structures

    4. Heavy base to counterbalance the rotating body

    5. Extremely high screening efficiency obtainable by means of individually adjustable retention time for any product and capacity
    6. 100% dustproof thanks to simple fast-mounting Silicone clip-on gaskets on the intermediate rings, thereby dispensing with the requirement to exchange the formerly used U-shaped gaskets on the screen inserts
    7. Delivered operationally ready and adjusted to each product

    8. Tough modular design, no dead corners, low part weights

    9. Easy dismantling and cleaning of all parts down to the conical base

    10. Low noise level of approx. 75 db(A)
    11. Automatic centering of screening inserts and strong intermediate rings and covers for simple and fast assembly and screen changing
    12. Optional: quick clamps for maximum time saving when changing screens

    13. Up to 7 fractions simultaneously on each machine
    14. Favorable prices and short delivery times

    15. Low construction height by means of reduced intermediate ring heights of 80 mm for best screen results on all decks


    Technical Parameters of Large Capacity Tumbler Screening Machine for Blast Furnace Pellets:

    ModelScreen Area (m²)Layers of ScreenMotor Power (KW)
    AM-6000.281~50.25
    AM-10000.721~51.5
    AM-12001.101~51.5
    AM-15001.801~52.2
    AM-18002.301~54.0
    AM-20002.601~54.0
    AM-23003.901~54.0
    AM-26005.301~55.5
    AM-29006.401~55.5

    BALANCE IS IMPORTANT !! Pneumatic Lifting Device


    Working Principle of Large Capacity Tumbler Screening Machine for Blast Furnace Pellets:

    The tumbler screener machine is an artificial imitation of shaking low frequency vibration sieve. The adjustment of the machine in response to the product to be screened provides an exactly defined three dimensional eccentric motion pattern with radial and tangential inclination.

    During the operation of the tumbler screening machine the radial inclination causes the product on the screen to move from the center towards the edge of the screen while the tangential inclination leads to a circular motion of the product on the screen. The combined impact of both of these forces causes the product in a helical motion of upon the surface of the screen and therefor to a relatively long retention time. This provides an optimized result on fraction separation while at the same time minimizing the amount of remaining outsize particles.



    Application of Large Capacity Tumbler Screening Machine for Blast Furnace Pellets:

    1. Abrasive material and ceramic industry: abrasive, refractory material, slurry, building sand, mica, alumina, etc.

    2. Chemical industry: resin pigment, grease, paint, medicine, palette, etc.

    3. Food industry: starch, milk powder, yeast powder, sugar, salt, alkali, gourmet powder, pollen, food additive, bean milk, juice etc.

    4. Metallurgy and mining industry: quartz sand, ore, titanium oxide, zinc oxide, etc.
    5. Paper-making industry: coated slurry, exhaust liquid, paper making liquid and waste water reclamation, etc.


    Important Information About Large Capacity Tumbler Screening Machine for Blast Furnace Pellets:

    Motioninvolute spiral motion
    Screening Accuracyupto 90%~99.9%
    Mesh Cleaning Methodbouncing ball cleaning, ultrasonic cleaning, brush cleaning, air cleaning, ultrasonic air cleaning, air brush cleaning
    Screen Structurewhole adhesive screen, or splicing segmented screen etc.
    Layers of Screen1~5 layers of screen
    Diameter600mm, 1000mm, 1200mm, 1400mm, 1500mm, 1600mm, 1800mm, 2000mm, 2100mm, 2300mm, 2600mm, 2900mm etc.
    Advantagessoft rock screening will not destroy the particles original structure of the material and not easy to produce static electricity
    Optionalquick clamps, pneumatic lifting devices etc.
    Applicationcan be used for material that is flammable, explosive and easy to generate static
    Motor BrandSiemens, ABB, BEGEMA etc.
    Surface Treatmentpolishing, sandblast, paint spraying etc.
