JGX-0480 Series Wire Rope Vibration Isolator Technical Support And Customized Solutions JGX-0480D-18A

    Buy cheap JGX-0480 Series Wire Rope Vibration Isolator Technical Support And Customized Solutions JGX-0480D-18A from wholesalers

    Buy cheap JGX-0480 Series Wire Rope Vibration Isolator Technical Support And Customized Solutions JGX-0480D-18A from wholesalers
    • Buy cheap JGX-0480 Series Wire Rope Vibration Isolator Technical Support And Customized Solutions JGX-0480D-18A from wholesalers
    • Buy cheap JGX-0480 Series Wire Rope Vibration Isolator Technical Support And Customized Solutions JGX-0480D-18A from wholesalers
    • Buy cheap JGX-0480 Series Wire Rope Vibration Isolator Technical Support And Customized Solutions JGX-0480D-18A from wholesalers

    JGX-0480 Series Wire Rope Vibration Isolator Technical Support And Customized Solutions JGX-0480D-18A

    Ask Lasest Price
    Brand Name : Hoan
    Model Number : JGX-0480D-18A
    Certification : ISO9001:2015
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 4,pience,7
    Delivery Time : 7
    • Product Details
    • Company Profile

    JGX-0480 Series Wire Rope Vibration Isolator Technical Support And Customized Solutions JGX-0480D-18A

    JGX-0480 Series

    The successful application of JGX-0480 series wire rope vibration isolator is inseparable from our strict control of quality. We follow the international quality management system standards, from the selection of raw materials to every link of the production process, strict quality control. Our team of engineers has the experience and expertise to continuously optimize production processes and improve the performance and reliability of our products. In addition, we provide comprehensive technical support and consulting services to help customers choose the most suitable product for their needs and provide personalized solutions


    Looking ahead, with the advancement of science and technology and changes in the market, we will continue to invest in research and development and constantly explore new materials and technologies to meet the changing market demand. We believe that through continuous innovation and improvement, JGX-0480 series wire rope vibration isolator will exert its excellent performance in more fields and create a safer and more comfortable living environment for human beings.


    In short, JGX-0480 series wire rope vibration isolator is an excellent product that combines high performance, strong stability and wide adaptability. It not only shows strong strength in the military field, but also has a wide range of application prospects in the civilian field. We will continue to uphold the principle of quality first and customer first, provide customers with the best quality products and services, and jointly create a better future.


    No.Model

    Max Static Load

    (kg)

    Max Deflection

    (mm)

    Kv(vibration)

    (Knm)

    Ks(shock)

    (Knm)

    1JGX-0480D-75A758.6578363
    2JGX-0480D-72A7211.7455252
    3JGX-0480D-61A6113.7347189
    4JGX-0480D-59A5915.7301152
    5JGX-0480D-52A5218.8244117
    6JGX-0480D-50A5020.821296
    7JGX-0480D-37A3726.913658
    8JGX-0480D-24A2429.58233
    9JGX-0480D-18A1836.65421
    10JGX-0480D-12A1252.82910

    No.Model

    Max Static Load

    (kg)

    Max Deflection

    (mm)

    Kv(vibration)

    (Knm)

    Ks(shock)

    (Knm)

    1JGX-0480D-75A54.512.7341179
    2JGX-0480D-72A52.216.8258126
    3JGX-0480D-61A44.119.819793
    4JGX-0480D-59A41.722.917275
    5JGX-0480D-52A38.126.914158
    6JGX-0480D-50A35.72912349
    7JGX-0480D-37A26.538.17728
    8JGX-0480D-24A18.141.74918
    9JGX-0480D-18A13.951.33311
    10JGX-0480D-12A9.374.7185.3

    No.Model

    Max Static Load

    (kg)

    Max Deflection

    (mm)

    Kv(vibration)

    (Knm)

    Ks(shock)

    (Knm)

    1JGX-0480D-75A36.38.6224224
    2JGX-0480D-72A36.311.7156156
    3JGX-0480D-61A34.114.7112112
    4JGX-0480D-59A31.716.89393
    5JGX-0480D-52A29.519.87070
    6JGX-0480D-50A27.221.86060
    7JGX-0480D-37A20.427.93535
    8JGX-0480D-24A5.931.01111
    9JGX-0480D-18A4.139.15.35.3
    10JGX-0480D-12A2.255.92.32.3

    * The material of the mounting splint *

    Stainless Steel or Aluminum can be selected

    * Surface treatment options for aluminum alloy plywood *

    * White Anodizing: The surface treatment to make the aluminum surface harder than itself. The color of the white anodized aluminum mounting bars keep the same color as the aluminum itself. It is the normal surface treatment of the aluminum mounting bars;
    * Hard Anodizing: The surface treatment to make the aluminum mounting bars much more harder than the white anodized way. The color of the hard anodized aluminum mounting bars is more darker than the white anodizing way. Special use for complex or special requirements of the working conditions of the using of wire rope isolators.
