Product Description
Main Features:
High-speed Servo Control, Full Closed-loop Positioning (to Ensure
Accurate Output of Various Unexpected Situations)
Independent Output Manager Supports File Background Automatic
Queuing Printing
Using advanced SOPC technology
Support breakpoint resume, ensure reliable data transmission and
printing
Two Directions High Speed Printing
Super EPSON Ink Box, Big Capacity Continuous Ink Supply. Easier
Operation to add the Ink.
No need to replace the Ink Box, More Environmental Friendly and
More Economic.
| Technical Parameters |
| Type: | Big Capacity EP20L Ink Box Continuous Ink Supply, No Ink Box
Replacement |
| Product Model | EP20-19 | EP20-21 | EP20-23 | EP20-25 |
| Printing Width(cm) | 190 | 210 | 230 | 250 |
| Feeding Paper Width(cm) | 200 | 220 | 240 | 260 |
Printing Speed: Two-way high speed 120 m2/h
Printing format: HPGL drawing language,compatible with domestic and
foreign CAD software,special format can be customized
Print resolution: 150-600DPI
Type of Nozzle: EP20L
Line quality: Clear,smooth,no seam,optional 1-8 lines
Nozzle Cleaning: Automatic cleaning before printing
Paper Loading: Front heightening device to support paper roll with
diameter of 28cm
Paper Feeding: Hidden infrared precise paper feeding
system,continuous 700 meters without deviation
Receiving and Delivering Paper: Unattended automatic paper
receiving and feeding
Print Media: 40-80g,ordinary roll printing paper; 80-250g,single
brown paper
Communication Interface: Network port,multiple computers can
separately control printing
Power Supply Voltage: 220V/50Hz, 110V, 60Hz Optional
Button Panel: Press the keys operation,simple,convenient,durable
Machine Structure: Die standardized metal structure,high precision
and long life
Output Center: 1.support manual or automatic printing 2.optional
ink-saving mode 3.support online printing
File Format: HP-GL, PLT, DXF, etc
Working Temperature: 10~35℃ or 50~95℉; Humidity: 15%--85% RH(With
no Condentation)
Company Information
Since its establishment, GEMEI has developed a series of cutting
machines for clothing, bags, shoes and hats, and obtained a number
of software copyright and patent certificates. Based on the
profound understanding of China’s garment, luggage and footwear
industry, GM series of cutting machine combines the essence of
Chinese and foreign technologies, closely combines the advantages
of the world's advanced technology and Chinese manufacturing
industry, adopts a novel design different from the domestic
traditional cutting machine, and fully experiences the design
principle of "good at core, simple in shape". After the first
continuous drum cutter came into being in the middle part of China
, we successively developed the sample cutter for the luggage
industry and continuous cutting garment sample cutter.
"The competition of enterprises is the competition of talents."
GEMEI firmly grasps the trend that the world manufacturing
industry is transferring to the middle part of the world, and has
established a research and development team composed of doctors and
senior engineers and other high-quality talents,and insists that
"innovation" is the eternal power of the development of GEMEI.
FAQ
1. Q: Are you a manufacturer?
A: Yes, we are specializing in the r&d production for template
cutter/inkjet cutter/pen writing cutter/cnc digital fabric
cutter/graph plotter in this field for 10 years.
2. Q: How do you pack these products?
A: Usually packed in wooden case and can pack according to export
standard or your requirement.
3. Q: Is it customizable?
A: Yes, We have basic sizes commonly applied in the field and can
customize according to your requirements.
4.Q: After-sales service
A: Yes, professional after-sales team and 24-hour technical support
by phone, email or skype
5.Q: What is your lead time?
A: Spot goods usually take 2-4 days, and customization takes 5-7
days
