    Portable Cable Fault Pinpointer for Customized Traditional Acoustic Testing

    XHDD503 Underground Cable Fault Pinpointer


    Product Description


    Description
    The XHDD503 cable fault locator is very small and light, it is packed in a protective PVC case, easy to carry after the user finished detection.

    The XHDD503 power cable fault pinpointer is designed with a microammeter display, with electrical level adjustment, frequency adjustment and volume adjustment knobs. By observing the swing of pointer on the microammeter, you can see the magnetic field strength during the flashover discharge at the fault point. Rotate the electrical level knob to adjust the reference of the magnetic field strength. In the process of path detection, adjusting the receiving frequency can make our ears hear the path signal that is easier to identify. Adjusting the frequency knob during the process of fault location can effectively avoid the radio signal. Adjust the volume during cable fault location and cable path finding, so that our ears hear a more appropriate sound signal.



    Technical Parameters

    Magnification500,000 times
    Positioning accuracy±0.2m
    Output impedance350Ω
    Working power supplyStandard 3.7V 3200mAh battery 4 cells
    Quiescent current<10mA
    Detection depth:More than 10 meters
    Working conditionsAmbient temperature: -25~65ºC; Relative humidity: ≤90%.



    Product Features
    1. Synchronously receive vibration waves, sound waves and electromagnetic waves generated during discharge at the fault point;
    2. The acoustic and magnetic channels are designed separately and powered separately, with stronger anti-interference ability;
    3. Super magnification, detection depth is greater than 10 meters;
    4. Ultra-low and low-power design, quiescent current is less than 10mA, and continuous operation is more than 20 hours;
    5. Analog meter design, signal strength and trend are clear at a glance;
    6. Zero level can be adjusted arbitrarily, suitable for various strong and weak scenes.


    Packing List



    Traditional Acoustic Testing High Quality Portable Cable Fault Pinpointer
