HX6020 Automatic Laser Cutting System With Loading And Unloading

Automatically complete the feeding, cutting and blanking of sheet metal, realize the batch continuous processing of single specification sheet metal, significantly improve the processing efficiency and reduce the comprehensive production cost.It is composed of multi-layer material storage system, multiple laser cutting host, automatic loading/unloading system, which greatly improves the labor production efficiency and the automation level of sheet met factory, and promotes the transformation and upgrading of manufacturing industry.It can carry out batch processing of multiple varieties and specifications of plates, and can realize communication and data sharing with production management system.


NameUnitHX3015HX4020HX6020
Processing rangemm3000*15004000*20006000*2000
X-axis strokemm155020502050
Y-axis strokemm305040506050
accelerationG1.51.51.5
Positioning accuracymm±0.03±0.03±0.03
Repeated positioning accuracymm±0.02±0.02±0.02
Laser generator powerW1000--30000

(The workpiece sorting system can be selected according to the need)
