    Three-Phase Intelligent Electricity Meter Calibration Device Stationary Meter Test System

    Ask Lasest Price
    Brand Name : GENY
    Model Number : YC-1893G
    Certification : ISO, CE
    Price : negotiate rates
    Payment Terms : T/T, L/C, D/P, T/T
    Supply Ability : 5 sets / 1 months
    Delivery Time : 6~8weeks
    • Product Details
    • Company Profile

    Three-Phase Intelligent Electricity Meter Calibration Device Stationary Meter Test System

    Three-Phase Intelligent Electricity Meter Calibration Device Stationary Meter Test System

    The YC-1893G three-phase intelligent electricity meter calibration device is designed and manufactured in accordance with the requirements of the State Grid (Southern Grid) intelligent electricity meter series standards, and it fully takes into account the characteristics of different users such as power supply, metering systems, and electricity meter manufacturers, fully capable of meeting their calibration needs.


    Product Details:


    Main Technical SpecificationsDescription
    Power SupplyThree-phase four-wire 3×220V/380V±15%, 50/60Hz±2Hz
    Ambient Temperature-10℃ to +40℃
    Ambient Humidity35% to 85% R.H.
    Output Voltage Range3×0~480V
    Output Voltage Power>10VA (per meter position/phase)
    Voltage Resolution≤0.01%
    Voltage Stability≤0.02%/120s
    Load Change Rate≤0.01%
    Voltage Distortion≤0.3% (full linear load range)
    Output Current Range3×0~120A
    Output Current Power>15VA (per meter position/phase)
    Current Resolution≤0.01%
    Current Stability≤0.02%/120s
    Current Distortion≤0.3% (full linear load range)
    Phase Adjustment Range0~360°
    Phase Resolution0.01°
    Frequency Adjustment Range45~65Hz
    Frequency Resolution0.01Hz
    Output Power Stability≤0.02%/120s
    Error DisplaySignal Reading: Read from electronic pulse signal end or LED optical signal end<br>Display Method: LED digital display
    Communication ProtocolFully complies with the regulations of DL/T645-2007 and its two filing documents DL/T645-2009-001/002.

    Functions:

    • Starting and creeping performance test
    • Forward and reverse active power and energy error test
    • Four-quadrant reactive power and energy error test
    • Energy error test under balanced and unbalanced loads
    • Meter reading error test
    • Meter combination error test
    • Verification of calibration constant
    • RS485 communication test
    • Daily timing error test
    • Time slot switching error test
    • Demand reading error test
    • Demand cycle error test
    • Error consistency test
    • Load current step change test

    Special Features:

    • Combined active and reactive power mode test
    • Tariff time period energy reading error test
    • Remaining energy decrement accuracy test
    • Local and remote fee control function test
    • Tiered electricity price switching function test
    • Built-in and external load switch performance test
    • Current overload performance test
    • Short-term overvoltage performance test
    • Time-segment maximum demand test
    • Infrared and carrier communication test (optional)
    • Power consumption test (optional)
    • Voltage, frequency, harmonics, and other influencing factor tests
