GE Datex Ohmeda 879484-3 ID 880767 Module
►Quick Detail:
The Datex anesthesia monitor is widely used in operating rooms and
has detection functions for parameters such as electrocardiogram,
respiration, non-invasive pressure, end expiratory carbon dioxide,
and blood oxygen saturation.
This is Datex Ohmeda 879484-3 ID 880767 Module,It can be used on GE's anesthesia machine .
Anesthetic agents
Measurement range:
Sevoflurane: 0 vol% to 8 vol%
Desflurane: 0 vol% to 20 vol%
Isoflurane, enflurane, halothane: 0 vol% to 6 vol%
Accuracy: ±(0.15 vol% +5% of reading)
Total system response time: < 3.1 s (< 3.5 s for Halothane)
Rise time: < 420 ms (< 800 ms for Halothane)
Hal drift: < 0.1 vol%
Enf drift: < 0.1 vol%
Iso drift: < 0.1 vol%
Sev drift: < 0.1 vol%
Des drift: < 0.3 vol%
EtAA and FiAA values are updated breath-by-breath.
The module automatically identifies the anesthetic agent present in
the sampled gas and measures the
concentration of the identified agent.
►Notes:
If there is a module malfunction and the CO2 test signal and values
are not displayed after startup, and an "occlusion" alarm message
appears, based on this fault phenomenon, the first step should be
to rule out whether the sampling tube and water cup are blocked.
Replace the sampling tube and water cup with new ones. If the fault
disappears, it should be a problem with the external air circuit;
If the fault persists, you can proceed with the following steps to
check.
First, press the software switches 1, 2, 3, and 4 on the panel in
sequence, and then quickly press the "RETURNTOMONITOR" button until
the letter "S" flashes on the display screen. Then press the
software "4" button to enter the "GASSERVICE" menu, where you can
view the values of the two parameters, pamb (atmospheric pressure)
and pint (suction pressure). Normally, the displayed value of pamb
is 760mmHg (1mmHg=1.33322 × 102Pa), and the pint is around -40mmHg.
If the deviation between pamb and pint values is too large, or if
the pint value cannot quickly rise to more than -100mm Hg when the
sampling tube's inlet is blocked, it is determined to be a gas
module fault.
►Key features:
| Type: | GE Datex Ohmeda Module |
| Warranty period: | 90 Days |
| Shipping Date: | 3-5 Working Days |
| MODEL: | 879484-3 ID 880767 Module |
| Storage temperature: | -20-70°c |
| MOQ: | 1 PCS |
| COLOR: | Black |
| Delivery Date: | 3 - 5 Working Days |
| Package | Standard export packaging |
