98000CPH high speed LED display driver baord SMT pick and place
machine
Machine main features
Integrated Placement Head
Lightweight, head is integrally formed, the 10 sets of Z axes are
independently controlled by modular magnetic linear motor, which
greatly improves the speed, accuracy and stability
Precision Corner System
The modular corner system independently controls the angle of each
component to ensure high-precision placement. 10 suction nozzles
per head, with a center distance of 16mm.
Vacuum Sensing Device
Each placement head with independent detection function, which
improves the stability of the equipment and the reliability of the
product.
Ultra-high-speed Capability
Adopting high-end magnetic linear motors and a multi-function
Modular head, the placement capability has increased by 25%
compared to traditional machines,with an optimum speed reaching
98000CPH
Machine main parameter
| Model | YT20S |
| Dimension |
| Length | 1480mm |
| Width | 2680mm |
| Height | 1650mm |
| Total Weight | 2380kg |
| PCB |
| PCB Length Width | Max:500*300mm(1200*450 option) Min:50*50mm |
| PCB Thickness | 0.5-5mm |
| PCB Clamping | Cylinder clamping, track width adjustable |
| Mounting Mode | Group picking and separate placingseparate picking and separate
placing |
| O.S. |
| System | Windows7 |
| Software | R&D independently |
| Display | LED monitor |
| Input Device | Keyboard, Mouse |
| Vision System |
| No. of Camera | 1 PCS (Head flight vision camera) |
| 2 PCS Mark camera |
| Mounting Precision | CHIP±0.03mm QFP±0.025mm Cpk ≧1.0 (3σ) |
| Mounting Height | ≦16mm (Other height can be customized) |
| Mounting Speed | 98000 CPH(Under best condition) |
| Components | 0201~12MM packaging material and IC material(Optional fixed camera
for 0201~35*35MM),Other component size can be customized |
| Components Space | 0.2mm |
| No. of Feeders Station | 104 PCS |
| No. of nozzles | 20 PCS |
| Power | 220AC 50HZ |
| Power Consumption | 1.5kw |
| Operating Environment | 23℃±3℃ |
| Transmission Speed | ＞1000mm/sec |
| Transmission Direction | Single(left→ right or right→ left) |
| Transmission Mode | Online drive |
| Position Mode | Optical |
| Gas consumption | 0.4-0.6mpa (4-6kgf/cm2)600N/min |
| Electrical control | Independent research and development by ETON |
| Motion control card module 1 set | Independent research and development by ETON |
| X,Y,Z Axis Drive way | High-end magnetic linear motor |
| Feeding way | Intelligent feeder with double motor |
| Production management MES system interface | Customized |
Certificates
As a seasoned leader in the SMT machine manufacturing industry, we
have garnered a multitude of intellectual property technologies,
boasting an impressive portfolio that includes 14 invention
patents, 135 practical patents, and 55 software copyrights. Our
commitment to innovation is further exemplified by our dedicated
in-house Research and Development department, ensuring cutting-edge
production and inspection capabilities.
Packages
Step 1: Wrap with stretch film to prevent the equipment from.
Step 2: Vacuum paper packaging and moisture-proof bag, so that the
machine can be kept dry during transportation to prevent moisture.
Step 3: Use straps and triangular wood to fix the machine to
prevent damage to the machine during transportation.
Step 4: Each exported machine will be equipped with sturdy export
wooden boxes, to ensure that the delivered product is good.
Shipping and Delivery
We usually transport the goods to the port in containers and then
ship them to the destination. For the transportation of machines,
land transportation and air transportation are also possible.
Service
Maintenance period 1 year
One year warranty during warranty any parts that need to be
repaired and replaced will be free.
Software and hardware lifetime maintenance
Free upgrade software, the software is Reach and developed by ETON,
so we support whole lifetime free upgrade updates.
Visit customers regularly and gather information
Visit clients regularly. We attend the different exhibitions in
different cities every year, at the same time, we will visit local
clients and support our service and collect feedback on customer
suggestions in time.
Provide the latest information about technology and equipment
We give professional technology suggestions to our clients. And
share the updated news with our clients
On-site service
We have some official site in India as Mumbai and New Delhi, also
have site in Egypt, Turkey that can provide service timely with our
engineers.
According to your needs, dedicated senior engineer will come to
your factory for free install and training you how to operate the
machine.
FAQ
Q: Does your machines have quality certificates?
A: We are high-tech enterprise with CE, SIRA, CCC , ISO awarded as
"Well-know brand" and many technology patents, and have rich
experience (more than 13 years) in LED light production line
program.
Q: why should you buy from us not from other suppliers?
A: We are high-tech professional manufacturer of SMT machine with
more than 13 years with good quality and reputation. We have rich
experience in helping client to start new factory and new line.
"Professional, high-effective, cost-saving" are our advantages.
