    GSC BDF Underground Water Reservoir Tank Large Rectangular Sectional Steel Water Tanks

    Ask Lasest Price
    Brand Name : JIAN ZHONG
    Model Number : GSC-BDF-1
    Certification : ISO 9001
    Price : customized
    Payment Terms : L/C, T/T, D/P, D/A
    Delivery Time : 7 work days
    • Product Details
    • Company Profile

    GSC BDF Underground Water Reservoir Tank Large Rectangular Sectional Steel Water Tanks

    GSC BDF Underground Water Reservoir Storage Tank Large Rectangular Steel Sectional Water Tank

    Overview
    Products Description
    BDF water tank
    BDF stainless steel water tank is a water tank product made of new materials, connected by screws (with a water stop strip sandwiched in the middle). BDF plate is a new type of plate in the water tank industry, with the following naming meanings: B is the letter for "stainless steel", D is the letter for "galvanized plate", and F is the letter for "composite". BDF plate is a composite of stainless steel plate and galvanized plate. The side in contact with water is lined with stainless steel plate to ensure water quality and corrosion resistance, and the outer side is a thicker galvanized steel plate to provide overall strength and stiffness.

    Potable Water Storage

    BDF tanks are widely used for storing drinking water. The corrosion-resistant stainless steel plate ensures that the water remains free from contamination and safe for consumption.

    Agricultural Water Storage

    Farmers use BDF water tanks to store water for irrigation purposes. These tanks can be buried deep underground, and the growth of crops on the ground will not be affected. Ensuring water storage on the farm.

    Firefighting Water Reserves

    BDF tanks are often employed to store water for firefighting purposes. These tanks can be strategically placed in areas prone to wildfires or where access to water is limited, will not occupy the fire-fighting space on the ground.

    Rainwater Harvesting

    BDF tanks can be used in rainwater harvesting systems to collect and store rainwater for various purposes, including landscape irrigation and non-potable water needs.

    Factory Water Storage

    Factories usually require a large amount of water for production and daily life. Most factories have limited space and do not want to sacrifice production space. BDF water tanks are a good choice.

    Emergency Water Supply

    In areas prone to water shortages or natural disasters, BDF water tanks can be used to store emergency water supplies. This ensures that communities have access to clean water during challenging circumstances.
    Specification
    Height
    (MM)
    Bottom Board
    (mm)
    Side 1
    (mm)
    Side 2
    (mm)
    Side 3
    (mm)
    Side 4
    (mm)
    Side 5
    (mm)
    Top board
    (mm)
    1000
    3
    3
    3
    1500
    3
    3
    3
    3
    2000
    3
    3
    3
    3
    2500
    4
    4
    3
    3
    3
    3000
    4
    4
    3
    3
    3
    3500
    4
    4
    3
    3
    3
    3
    4000
    5
    5
    4
    3
    3
    3
    4500
    5
    5
    5
    4
    3
    3
    3
    5000
    5
    5
    5
    4
    3
    3
    3
    Product packaging
    Customer Photos
    Company Profile

    1.Are you factory or trade company? We are manufacture.

    2.What's the guarantee, in case the water tank breaks down?
    The water tank has one year s guarantee. If it breaks down, generally speaking, our technician will figure out what the problem
    may be, according to clients feedback.Parts will be replaced for free if the problems are caused by quality fault.

    3.How about the documents after shipment?
    After shipment, we will send all original documents to you by DHL, including Packing List, Commercial Invoice, B/L, and other
    certificates as required .

    4.How long is the delivery time?
    For standard water tank less than 100m3, it would be 7-10 days; For non standard water tank and customized water tank according to
    client s specific requirements, it would be 15 to 30 days.

    5.How's the payment?
    Telegraphic Transfer(T/T). L/C at sight .

    6.Do You Arrange Shipment For The Machines?
    Yes, dear esteemed customers, for FOB or CIF price, we will arrange shipment for you. For EXW price, clients need to arrange
    shipment by themselves or their agents.

    7.How is the packing?
    Solid Seaworthy plywood Box Package with Steel Belt Save space as much as possible for container loading.

    What is GSC Water Tank?

    GSC modular water tank is Galvanized and Stainless Steel Compound water tank.Made from 3 types of raw materials.Inner is stainless steel plate and outer is hot dip galvanized plate with one layer of high modular materials sandwiched.High pressure and high temperature to form this new type of compound plate.Because of inner stainless steel plate and outer steel structure,it has the advantages of storing drinking water. GSC modular water tank could be applied either ground or underground used for rainwater colletion, which effectively solved tight earth issues by underground water tank application.
    Our Advantages

    ANTI-CORROSION

    GSC water tank inner stainless steel materials,outer hot dip galvanized materials,which decides the good anti-corruption from outside and drinking water storage from inside.

    RELIABLE QUALITY

    This panel is new type of materials,meet drinking water use and mainly used underground,overground for its better structure.

    DIMENSION FLEXIBILITY

    The size of panel can be 1.22*1.22 m, 1*1 m, 1*0.5 m and 0.5*0.5 m, which can assemble kinds of volume from 0.125 m³ to 5000 m³. That’s extremely convenient to select for you.

    CONVENIENT INSTALLATION

    Factory precast panels are easy to assemble and disassemble, the construction drawing, installation video, and a series of complete installation plan will be provided.

    DURABLE

    Using the 1000 T hydraulic press integrated molding, no welding seam at panel corners.

    BURY UNDERGROUND

    All the HUILI steel material water tank can be bury underground, the thickness of inner structure and panels are thicker than normal tank.
    Details Images
    TANK HEIGHT
    THICKNESS OF EACH PANEL
    Bottom Board
    Side 1
    Side 2
    Side 3
    Side 4
    Side 5
    Top board
    1000 mm
    3 mm
    3 mm
    /
    /
    /
    /
    2 mm
    1500 mm
    3 mm
    3 mm
    3 mm
    /
    /
    /
    2000 mm
    3 mm
    3 mm
    3 mm
    /
    /
    /
    2500 mm
    4 mm
    4 mm
    3 mm
    3 mm
    /
    /
    3000 mm
    4 mm
    4 mm
    3 mm
    3 mm
    /
    /
    3500 mm
    4 mm
    4 mm
    3 mm
    3 mm
    2.5 mm
    /
    4000 mm
    5 mm
    5 mm
    4 mm
    3 mm
    2.5 mm
    /
    4500 mm
    5 mm
    5 mm
    5 mm
    4 mm
    3 mm
    2.5 mm
    5000 mm
    5 mm
    5 mm
    5 mm
    4 mm
    3 mm
    2.5 mm
    PANEL DIMENSION
    WEIGHT OF EACH PANEL
    2 mm
    2.5 mm
    3 mm
    3.5 mm
    4 mm
    5 mm
    0.5*0.5m
    6 kg
    7.5 kg
    9 kg
    10.5 kg
    12 kg
    13.5 kg
    1*0.5m
    11 kg
    13.5 kg
    16.5 kg
    19 kg
    22 kg
    24 kg
    1*1m
    19 kg
    24 kg
    29 kg
    34 kg
    39 kg
    43 kg
    Physical Properties
    Standard Requirement
    Result
    Tensile Strength
    ≥350 MPa
    405 MPa
    Yield Strength
    ≥220 MPa
    296 MPa
    Elongation
    ≥23%
    24%
    Why Choose Us
    Product packaging
    FAQ

    Q: Are you trading company or manufacture?

    A: We are factory.

    Q: How long is your delivery time?

    A: Generally it is 5-10 days if the goods are in stock. Or it is 10-15 days if the goods are not in stock, it is according to the quantity.

    Q: Do you provide samples? is it free or extra?

    A: Yes, we could offer the sample for free charge but do not pay the cost of freight.

    Q: What is your terms of payment?

    A: Payment <= 1000usd="">= 1000USD, 30% T/T in advance, balance before shippment. If you have other questions, pls feel free to contact us as below:
