Full Redundancy
A backup can be installed for both power and signal
Low gray and high brightness technology
Even at low brightness levels of 100cd/㎡ to 300cd/㎡, it can
perfectly present dark details, and there will be no grainy,
blurry, or distorted images when viewed up close
4:3 Ratio
Cabine size W640*H480mm,the screen size ratio is always 4:3
When there are the same amount of cabinets vertically and
horizontallyHigh definition and high refresh rate
Up to 3840Hz refresh, no shaking or ghosting in the playback
screen, no water ripple phenomenon；
Slim and Light
Ultra slim cabinet design , cabinet weight 7.47kg/pcs
Easy Installation
4 plates at the corners of each cabinet can be dismounted easily,
Easier for installation for front service screens
Application Scenarios
advertising publish, retail store, shopping mall, welcome display,
airport, subway, elevator, Restaurant & Hotel Supplies, education,
hotel lobby, school classroom, exhibition centre hallway
About GCL :
The focus of GCL lies in the manufacturing of various types of LED
display screens, including indoor and outdoor displays, rental
displays, flexible displays, transparent displays, dance floor
series, high-definition resolution displays, perimeter displays,
stadium sport screens, LED signs, display boards and billboards.
Parameters of Gspark
| Product | P1.5 | P1.86 | P2 | P2.5 |
| Pitch | 1.538mm | 1.86mm | 2mm | 2.5mm |
| Density(pixels/m²) | 422500 | 288906 | 250000 | 160000 |
| LED Type | SMD1212 | SMD1515 | SMD1515 | SMD2020 |
| Brightness | 600nits | 700nits | 700nits | 700nits |
| Scan Method | 1/52 | 1/43 | 1/40 | 1/32 |
| Panel Size | 640×480mm |
| Module Size | 320×160mm |
| Panel Material | Die-casting Aluminum |
| Panel Weight | 7 kg |
| Protection Level | IP31 |
| Maintenance | Full Front Service |
| Max Power Consumption | 450W/㎡ | 450W/㎡ | 450W/㎡ | 450W/㎡ |
| Average Power Consumption | 150W/㎡ | 150W/㎡ | 150W/㎡ | 150W/㎡ |
| Refresh Rate | 3840Hz |
| Grey Scale | 13~16bit |
| Viewing Angle | H160°,V160° |
| Voltage | AC100~240V(50-60Hz) |
| Working Temperature | -20℃to 60℃ |
| Working Humidity | 10%-90%RH |
| Color Temperature | 3000-9500K |
| Certifications | CE/ROHS/EMC/TUV/UL/CCC/FCC/ISO |
