USA Type Warehouse Steel Pallet Rack 3000IBS 4000Ibs Teardrop Style Pallet Racking

    Buy cheap USA Type Warehouse Steel Pallet Rack 3000IBS 4000Ibs Teardrop Style Pallet Racking from wholesalers

    Buy cheap USA Type Warehouse Steel Pallet Rack 3000IBS 4000Ibs Teardrop Style Pallet Racking from wholesalers
    • Buy cheap USA Type Warehouse Steel Pallet Rack 3000IBS 4000Ibs Teardrop Style Pallet Racking from wholesalers
    • Buy cheap USA Type Warehouse Steel Pallet Rack 3000IBS 4000Ibs Teardrop Style Pallet Racking from wholesalers
    • Buy cheap USA Type Warehouse Steel Pallet Rack 3000IBS 4000Ibs Teardrop Style Pallet Racking from wholesalers

    USA Type Warehouse Steel Pallet Rack 3000IBS 4000Ibs Teardrop Style Pallet Racking

    Ask Lasest Price
    Brand Name : Acerack
    Model Number : AR-SP1
    Certification : RMI / AS4084-2012 / CE / ISO9001
    Price : Negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 5000T/Month
    Delivery Time : 15-25days
    • Product Details
    • Company Profile

    USA Type Warehouse Steel Pallet Rack 3000IBS 4000Ibs Teardrop Style Pallet Racking

    USA Type Warehouse Steel Pallet Racks 3000IBS 4000Ibs Factory Direct Sale Teardrop Pallet Racks

    Teardrop pallet rack are one of the most common types of pallet racks used by warehouse storage and distribution centers across America. Teardrop pallet rack is another name for roll formed selective pallet rack, which is commonly manufactured in a teardrop style (nicknamed because the holes on the column of the upright are shaped like a teardrop). Pallets then rest on the horizontal load beams that are held in place by mounting clips. Because the clips on teardrop configurations can be quickly removed, the shelves can be adjusted to different heights or reinforced to bear different weights to accommodate various load sizes.

    We're specialized in design and production of Pallet Racking and Shelving System, as well as Cantilever Rack, Mezzanine Platform, Radio Shuttle System, ASRS, Wire mesh deck etc.

    Name
    Pallet Rack
    Size
    Customized Size
    Material
    Steel
    Depth/Width/Height
    Customized
    Color
    Customized
    Weight Capacity
    500~5000kg
    Certification
    AS4084-2012 / CE / ISO / RMI
    Pitch holes
    50.8mm 75mm,76.2mm
    Surface finish
    Powder Coated
    Usage
    Warehouse Storage System
    Application
    Widely Used
    Free Sample
    Available (Delivery Cost on Buyer)
    OEM
    Available

    Name
    Teardrop (US) Pallet Rack
    Material
    Steel
    Depth
    Upright 1.5;2.0;2.5mm
    Weight Capacity
    1000-1500 Kg Per Pallet
    Width
    Customized
    Height
    Customized
    Frame Structure Type
    3"*3" Welded & Bolted Upright frame with Baseplate
    Beam Type
    3"-6" Step Beam
    Beam Connector Type
    SP & SL Safety Locker
    Surface finish
    Powder coating; Galvanized; Hot Dip Gavanized
    Application Environment
    Normal Temperature or Cold Room (Max -40C)
    Certification
    CE
    Free Sample
    Available (Delivery Cost on Buyer)
    OEM
    Available

    Features

    -100% selective of goods / pallets
    -Most economical to maximise warehouse space
    -Picking rate: Fast

    -Good stock / pallets rotation

    -Floor space utilization: 30% to 40%
    -Most popular application / solution to warehouse storage solution

    Teardrop pallet racking

    Teardrop pallet racking system is used for storing pallet packed products, by forklift operation. Main parts of the whole pallet racking include upright frames and beams, along with a wide range of accessories, like upright protector, aisle protector, pallet support, pallet stopper, wire decking, etc.

    Packaging & Shipping

    Standard export package by pallet and covered by plastic film:

    1. Q: Why choose us?
    A: Professional design team, adequate production capacity, comply with AS4084. RMI and FEM standard.


    2. Q: What is the material on your products?
    A: The material normally use is Q235B/D steel and also Q355B/D.


    3. Q: What is the packaging of the products?
    A: Standard export package by pallet and covered by plastic film.


    4. Q: What is the MOQ can order?
    A: Normally is one 20ft container, small quantities are also available.

    5. Q: What is the payment terms?
    A: We accept TT or L/C etc.

    6. Q: What is your delivery time?
    A: Normally is 2-4 weeks after receipt of the deposit.

    7. Q: Are samples available?

    A: Yes, we can send some sections of samples for your reference by express.
