Brand Name : | MARSHINE |
Certification : | CE, ISO |
Delivery Time : | 15-30DAY |
Payment Terms : | T/T, L/C, Western Union |
Supply Ability : | 2000PCS/Day |
Model Number : | SFS1-400 |
Price : | usd 200-800 pcs |
Two Bundle Conductor Inspection Trolley
Our Marshine's Two Bundle Conductor Inspection Trolley is used for
laying high-voltage cables on the cable trays and ground, the pay off pulley can effectively reduce cable friction and protect the cables, accelerating the speed of construction. With high strength materials and various choices, can
highly improve your effieciency.
Uses: to mount accessories and to overhaul.
Notes: should confirm the distance between conductors before proceeding
production
Technical Parameters
Item number | Model | Rated load (kN) | Maximum through Diameter (mm) | Conductor distance (mm) | Weight (kg) | Remark |
17251 | SFS2 | 1 | Φ40 | 400 | 34 | Horizontal |
450 | 36 | |||||
500 | 38 | |||||
17253 | SFS400 | 1 | Φ40 | 400 | 40 | Vertical |
17255 | FC400/450S | 1 | Φ60 | 400~450 | 34 | Horizontal |
17256 | SFS1-400 | 1.5 | Φ70 | 400 | 38 | Horizontal |
17257 | SFS1-450 | 1.5 | Φ70 | 450 | 40 | Horizontal |
![]() |
